Audi A7 II (2018-2023) engine pre-wiring coupling point 2 Wiring diagrams
This page contains all the electrical diagrams for the component. engine pre-wiring coupling point 2, in which he is found in the car Audi A7 II (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
engine pre-wiring coupling point 2 wiring diagram (1 of 2)
ACCELERATOR PEDAL MODULE
AFTER-RUN COOLANT PUMP
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRAKE PEDAL SWITCH
CAMSHAFT ADJUSTMENT VALVE 1
CAMSHAFT ADJUSTMENT VALVE 2
CYLINDER 5 INTAKE CAM ACTUATOR 1
CYLINDER 6 INTAKE CAM ACTUATOR 1
ENGINE PRE-WIRING COUPLING POINT 2
ENGINE/MOTOR CONTROL MODULE
EXHAUST CAMSHAFT ADJUSTMENT VALVE 1
EXHAUST CAMSHAFT ADJUSTMENT VALVE 2
FROM MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY (DIAGRAM 7 OF 9)
FUEL PUMP CONTROL MODULE
FUEL TANK LEAK DETECTION MODULE
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL A
GRY/RED WIRE
LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
MAP CONTROLLED ENGINE COOLING THERMOSTAT
OIL LEVEL THERMAL SENSOR
OXYGEN SENSOR 1 (BEFORE CATALYTIC CONVERTER)
OXYGEN SENSOR 1 AFTER CATALYTIC CONVERTER
PISTON COOLING NOZZLE CONTROL VALVE
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
STARTER GENERATOR
STARTER/ GENERATOR COOLANT PUMP
TO COOLANT RECIRCULATION PUMP (DIAGRAM 8 OF 9)
TO ENGINE COMPONENT POWER SUPPLY RELAY (DIAGRAM 7 OF 9)
VIO/RED WIRE
WASTEGATE BYPASS REGULATOR VALVE
WHT/GRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (9 of 9) -> ENGINE PRE-WIRING COUPLING POINT 2
engine pre-wiring coupling point 2 wiring diagram (2 of 2)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CYLINDER BLOCK COOLANT VALVE
ENGINE PRE-WIRING COUPLING POINT 2
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/WHT WIRE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION COIL 6 W/ POWER OUTPUT STAGE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
MECHANICAL COOLANT PUMP SWITCH VALVE
NCA WIRE
OIL LEVEL THERMAL SENSOR
PISTON COOLING NOZZLE CONTROL VALVE
RED/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
TO SPARK PLUG 4
TO SPARK PLUG 5
TO SPARK PLUG 6
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (9 of 10) -> ENGINE PRE-WIRING COUPLING POINT 2
