Heated seats circuit, without ventilation for Audi A7 I (2010-2014)

BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BACKREST BOLSTER HEATER DRIVER SEAT HEATING ELEMENT FRONT PASSENGER BACKREST HEATING FRONT PASSENGER SEAT BACKREST BOLSTER HEATER FRONT PASSENGER SEAT HEATING ELEMENT FUSE FUSE PANEL D (UNDER LEFT SIDE OF DASH) GRN WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT SEAT HEATER LEFT FRONT SEAT TEMPERATURE SENSOR ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT HEATER RIGHT FRONT SEAT TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO WIRE W/ AUXILIARY HEATER WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE CARRIER FUSE CARRIER 1 FUSE FUSE FUSE CARRIER FUSE PANEL B FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) GRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HEATING ELEMENT HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT REAR BACKREST LEFT REAR BENCH SEAT RIGHT REAR HEATING HEATED SEAT ELEMENT TEMPERATURE SENSOR LEFT REAR HEATED SEAT REGULATING SWITCH LEFT REAR SEAT HEATER (W/O ADJUSTABLE SEATS) LEFT SEAT HEATING BUTTON NCA WIRE ORG/BLU WIRE ORG/BRN WIRE REAR A/C DISPLAY CONTROL HEAD (COMFORT) REAR SEATS) RED WIRE RED/BRN WIRE RED/VIO WIRE RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR HEATED SEAT REGULATING SWITCH RIGHT REAR HEATED SEAT TEMPERATURE SENSOR RIGHT REAR SEAT HEATER (W/O ADJUSTABLE SEATS) RIGHT SEAT HEATING BUTTON SEAT HEATING CONTROL MODULE VIO WIRE W/ BASIC AUTOMATIC A/C W/ COMFORT AUTOMATIC A/C YEL WIRE
