Audi A7 I (2010-2014) temperature sensor Wiring diagrams

This page contains all the electrical diagrams for the component. temperature sensor, in which he is found in the car Audi A7 I (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

temperature sensor wiring diagram (1 of 8)

BACKREST BOLSTER HEATER BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT BACKREST BLOWER FAN 2 DRIVER SEAT CUSHION BLOWER FAN DRIVER SEAT CUSHION BLOWER FAN 2 FRONT PASSENGER SEAT BACKREST BLOWER FAN FRONT PASSENGER SEAT CUSHION BLOWER FAN FRONT PASSENGER SEAT CUSHION BLOWER FAN 2 FUSE CARRIER FUSE 9 FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) GRN WIRE HEATING ELEMENT HEATING ELEMENT FRONT PASSENGER BACKREST HEATING ELEMENT HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL D FUSE 10 (UNDER LEFT SIDE OF DASH) LEFT FRONT SEAT HEATER LEFT FRONT SEAT VENTILATION CONTROL MODULE RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FRONT SEAT VENTILATION CONTROL MODULE SEAT TEMPERATURE SENSOR FRONT PASSENGER SEAT BACKREST BLOWER FAN 2 SIDE BOLSTER HEATER SIDE HEATING ELEMENT BOLSTER HEATER RIGHT FRONT SEAT HEATER TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO/WHT WIRE W/ AUXILIARY HEATER YEL WIRE

Go to component -> Front heated seats circuit, with ventilation -> TEMPERATURE SENSOR

temperature sensor wiring diagram (2 of 8)

BACKREST BOLSTER HEATER BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT BACKREST BLOWER FAN 2 DRIVER SEAT CUSHION BLOWER FAN DRIVER SEAT CUSHION BLOWER FAN 2 FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER SEAT BACKREST BLOWER FAN FRONT PASSENGER SEAT BACKREST BLOWER FAN 2 FRONT PASSENGER SEAT CUSHION BLOWER FAN FRONT PASSENGER SEAT CUSHION BLOWER FAN 2 FUSE 10 FUSE 9 FUSE CARRIER 1 FUSE PANEL D FUSE PANEL F GRN WIRE HEATING ELEMENT HOT AT ALL TIMES LEFT FRONT SEAT HEATER LEFT FRONT SEAT VENTILATION CONTROL MODULE RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FRONT SEAT HEATER RIGHT FRONT SEAT VENTILATION CONTROL MODULE SEAT TEMPERATURE SENSOR SIDE BOLSTER HEATER TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE W/ AUXILIARY HEATER YEL WIRE

Go to component -> Front heated seats circuit, w/ ventilation -> TEMPERATURE SENSOR

temperature sensor wiring diagram (3 of 8)

BLK/BRN WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT DRIVER DOOR CONTROL MODULE (IN DRIVER FRONT DOOR) DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT BACKREST BLOWER FAN 2 DRIVER SEAT CUSHION BLOWER FAN DRIVER SEAT CUSHION BLOWER FAN 2 FRONT PASSENGER DOOR CONTROL MODULE (IN FRONT PASSENGER FRONT DOOR) FRONT PASSENGER MEMORY SEAT CONTROL MODULE FRONT PASSENGER SEAT BACKREST BLOWER FAN FRONT PASSENGER SEAT BACKREST BLOWER FAN 2 FRONT PASSENGER SEAT CUSHION BLOWER FAN FRONT PASSENGER SEAT CUSHION BLOWER FAN 2 GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRY/BRN WIRE HEATING ELEMENT LEFT FRONT SEAT HEATER MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SEAT HEATING ELEMENT TEMPERATURE SENSOR RIGHT FRONT SEAT HEATER SIDE BOLSTER HEATER SIDE BOLSTER HEATER HEATING ELEMENT TEMPERATURE SENSOR YEL WIRE YEL/WHT WIRE

Go to component -> Heated seats circuit, with memory seats with ventilation -> TEMPERATURE SENSOR

temperature sensor wiring diagram (4 of 8)

BLK/BRN WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT DRIVER DOOR CONTROL MODULE DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT BACKREST BLOWER FAN 2 DRIVER SEAT CUSHION BLOWER FAN DRIVER SEAT CUSHION BLOWER FAN 2 FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER MEMORY SEAT CONTROL MODULE FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT BACKREST BLOWER FAN FRONT PASSENGER SEAT BACKREST BLOWER FAN 2 FRONT PASSENGER SEAT CUSHION BLOWER FAN FRONT PASSENGER SEAT CUSHION BLOWER FAN 2 GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRY/BRN WIRE HEATING ELEMENT HOT AT ALL TIMES LEFT FRONT SEAT HEATER MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT HEATER SEAT TEMPERATURE SENSOR SIDE BOLSTER HEATER TEMPERATURE SENSOR YEL WIRE YEL/WHT WIRE

Go to component -> Heated seats circuit, w/ memory seats w/ ventilation -> TEMPERATURE SENSOR

temperature sensor wiring diagram (5 of 8)

BLK/WHT WIRE BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE REAR MULTICONTOUR SEAT CONTROL MODULE DRIVER SIDE REAR SEAT ADJUSTMENT CONTROL MODULE DRIVER SIDE REAR SEAT LEFT BOLSTER HEATING ELEMENT DRIVER SIDE REAR SEAT RIGHT BOLSTER HEATING ELEMENT GRN/BRN WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/WHT WIRE HEATING ELEMENT HOT AT ALL TIMES LEFT REAR BACKREST BLOWER FAN LEFT REAR BACKREST HEATING ELEMENT LEFT REAR SEAT BLOWER FAN LEFT REAR SEAT HEATER NCA WIRE REAR A/C DISPLAY CONTROL HEAD RED/BLK WIRE RED/WHT WIRE SIDE BOLSTER HEATER TEMPERATURE SENSOR VALVE BLOCK 1 VALVE BLOCK 2 VIO/WHT WIRE

Go to component -> Rear heated seats circuit, with ventilation (1 of 2) -> TEMPERATURE SENSOR

temperature sensor wiring diagram (6 of 8)

BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER SIDE REAR MULTICONTOUR SEAT CONTROL MODULE GRN/BLK WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/WHT WIRE HEATING ELEMENT LEFT REAR BACKREST HEATING ELEMENT NCA WIRE PASSENGER SIDE REAR SEAT ADJUSTMENT CONTROL MODULE PASSENGER SIDE REAR SEAT LEFT BOLSTER HEATING ELEMENT PASSENGER SIDE REAR SEAT RIGHT BOLSTER HEATING ELEMENT RED/BLK WIRE RED/WHT WIRE RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR SEAT BACKREST BLOWER FAN RIGHT REAR SEAT BLOWER FAN SIDE BOLSTER HEATER TEMPERATURE SENSOR VALVE BLOCK 1 VALVE BLOCK 2 VIO/WHT WIRE

Go to component -> Rear heated seats circuit, with ventilation (2 of 2) -> TEMPERATURE SENSOR

temperature sensor wiring diagram (7 of 8)

BLK/WHT WIRE BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE REAR MULTICONTOUR SEAT CONTROL MODULE DRIVER SIDE REAR SEAT ADJUSTMENT CONTROL MODULE DRIVER SIDE REAR SEAT LEFT BOLSTER HEATING ELEMENT DRIVER SIDE REAR SEAT RIGHT BOLSTER HEATING ELEMENT DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 GRN/BRN WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/WHT WIRE HEATING ELEMENT HOT AT ALL TIMES LEFT REAR BACKREST BLOWER FAN LEFT REAR BACKREST HEATING ELEMENT LEFT REAR SEAT BLOWER FAN LEFT REAR SEAT HEATER NCA WIRE REAR A/C DISPLAY CONTROL HEAD RED/BLK WIRE RED/WHT WIRE SIDE BOLSTER HEATER TEMPERATURE SENSOR VALVE BLOCK 1 VALVE BLOCK 2 VIO/WHT WIRE

Go to component -> Rear heated seats circuit, w/ ventilation (1 of 2) -> TEMPERATURE SENSOR

temperature sensor wiring diagram (8 of 8)

BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER SIDE REAR MULTICONTOUR SEAT CONTROL MODULE FRONT PASSENGER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 2 GRN/BLK WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/WHT WIRE HEATING ELEMENT HOT AT ALL TIMES LEFT REAR BACKREST HEATING ELEMENT NCA WIRE PASSENGER SIDE REAR SEAT ADJUSTMENT CONTROL MODULE PASSENGER SIDE REAR SEAT LEFT BOLSTER HEATING ELEMENT PASSENGER SIDE REAR SEAT RIGHT BOLSTER HEATING ELEMENT RED/BLK WIRE RED/WHT WIRE RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR SEAT BACKREST BLOWER FAN RIGHT REAR SEAT BLOWER FAN SIDE BOLSTER HEATER TEMPERATURE SENSOR VALVE BLOCK 1 VALVE BLOCK 2 VIO/WHT WIRE

Go to component -> Rear heated seats circuit, w/ ventilation (2 of 2) -> TEMPERATURE SENSOR

Audi A7 I (2010-2014) temperature sensor Wiring diagrams

temperature sensor wiring diagram (1 of 8)

List of components:

temperature sensor wiring diagram (2 of 8)

List of components:

temperature sensor wiring diagram (3 of 8)

List of components:

temperature sensor wiring diagram (4 of 8)

List of components:

temperature sensor wiring diagram (5 of 8)

List of components:

temperature sensor wiring diagram (6 of 8)

List of components:

temperature sensor wiring diagram (7 of 8)

List of components:

temperature sensor wiring diagram (8 of 8)

List of components:
