Audi A7 I (2010-2014) roof shade control module Wiring diagram

This page shows the only wiring diagram for the component.roof shade control module, which is found in the car Audi A7 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram roof shade control module (1 of 1)

Wiring diagram roof shade control module for Audi A7 I (2010-2014)

Get access

BLU WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM FUSE 11 FUSE 7 FUSE CARRIER FUSE PANEL B (LEFT END OF DASH) GRN WIRE HOT AT ALL TIMES NCA WIRE POWER SUNROOF CONTROL MODULE (CENTER FRONT OF ROOF) RED WIRE ROOF SHADE BUTTON 2 ROOF SHADE BUTTON SUNROOF BUTTON ASSEMBLY ROOF SHADE CONTROL MODULE SUNROOF 6 7 8 9 10 MOTOR SUNROOF BUTTON SUNROOF SHADE MOTOR VIO/WHT WIRE WHT WIRE YEL WIRE

Go to component: -> Power top/sunroof circuit -> ROOF SHADE CONTROL MODULE
