Audi A7 I (2010-2014) rearview camera system control module (right side of luggage compt) wiring diagram
This page shows the only wiring diagram for the component.rearview camera system control module (right side of luggage compt), which is found in the car Audi A7 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rearview camera system control module (right side of luggage compt) wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
BRN/BLK WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
FUSE 10 FUSE CARRIER
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRN WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PINS: 1-38 (NOT USED) 39 40 41 42
REAR LID LOCK CYLINDER UNLOCK BUTTON
REARVIEW CAMERA (INTEGRAL TO REAR LID HANDLE)
REARVIEW CAMERA SYSTEM CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RED/GRN WIRE
W/ RMC SOUND SYSTEM W/O RMC SOUND SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear camera circuit -> REARVIEW CAMERA SYSTEM CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
