Audi A7 I (2010-2014) left rear air vent illumination bulb Wiring diagram
This page shows the only wiring diagram for the component.left rear air vent illumination bulb, which is found in the car Audi A7 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear air vent illumination bulb (1 of 1)
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 1 FUSE 11
FUSE CARRIER 2 FUSE 2
FUSE PANEL B (LEFT END OF DASH)
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRN WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT B-PILLAR/ FOOTWELL SHUT-OFF DOOR MOTOR
LEFT REAR AIR VENT ILLUMINATION BULB
LEFT REAR FOOTWELL VENT TEMPERATURE SENSOR (IN LEFT REAR FOOTWELL VENT ASSEMBLY)
LEFT REAR UPPER BODY VENT TEMPERATURE SENSOR (IN REAR UPPER BODY VENT ASSEMBLY)
ORG/BLU WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
REAR A/C DISPLAY CONTROL HEAD
RED WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR AIR VENT ILLUMINATION BULB
RIGHT REAR UPPER BODY VENT TEMPERATURE SENSOR (IN REAR UPPER BODY VENT ASSEMBLY)
SEATS SYSTEM
VIO/GRN WIRE
VIO/WHT WIRE
YEL WIRE
Go to component: -> Rear a/c circuit -> LEFT REAR AIR VENT ILLUMINATION BULB
