Audi A7 I (2010-2014) left front seat temperature sensor Wiring diagrams

This page contains all the electrical diagrams for the component. left front seat temperature sensor, in which he is found in the car Audi A7 I (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left front seat temperature sensor (1 of 2)

Wiring diagram left front seat temperature sensor for Audi A7 I (2010-2014)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BACKREST BOLSTER HEATER DRIVER SEAT HEATING ELEMENT FRONT PASSENGER BACKREST HEATING FRONT PASSENGER SEAT BACKREST BOLSTER HEATER FRONT PASSENGER SEAT HEATING ELEMENT FUSE FUSE PANEL D (UNDER LEFT SIDE OF DASH) GRN WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT SEAT HEATER LEFT FRONT SEAT TEMPERATURE SENSOR ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT HEATER RIGHT FRONT SEAT TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO WIRE W/ AUXILIARY HEATER WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Heated seats circuit, without ventilation (1 of 2) -> LEFT FRONT SEAT TEMPERATURE SENSOR

Wiring diagram left front seat temperature sensor (2 of 2)

Wiring diagram left front seat temperature sensor for Audi A7 I (2010-2014)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BACKREST BOLSTER HEATER DRIVER SEAT HEATING ELEMENT FRONT PASSENGER BACKREST HEATING FRONT PASSENGER SEAT BACKREST BOLSTER HEATER FRONT PASSENGER SEAT HEATING ELEMENT FUSE 10 FUSE PANEL D GRN WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT SEAT HEATER LEFT FRONT SEAT TEMPERATURE SENSOR ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT HEATER RIGHT FRONT SEAT TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE W/ AUXILIARY HEATER WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Heated seats circuit, w/o ventilation (1 of 2) -> LEFT FRONT SEAT TEMPERATURE SENSOR
