Audi A7 I (2010-2014) hot w/ motronic engine control module power supply relay energized Wiring diagrams

A/C COMPRESSOR REGULATOR VALVE (REAR OF COMPRESSOR) A/C PRESSURE/ TEMPERATURE SENSOR (ON A/C HIGH PRESSURE LINE) BLK/GRN WIRE BLU/BRN WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CHARGE AIR COOLING PUMP (IN LEFT FRONT WHEELWELL) COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM COOLANT FAN CONTROL (FC) MODULE (ON COOLANT FAN) COOLANT FAN CONTROL (FC) MODULE 2 (ON COOLANT FAN 2) COOLANT FAN FUSE ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENGINE) EVAPORATOR VENT TEMPERATURE SENSOR (RIGHT SIDE OF HVAC UNIT) FRESH AIR BLOWER CONTROL MODULE (LOWER RIGHT SIDE OF DASH) FRONT MEMBER) FUSE CARRIER 1 FUSE FUSE FUSE FUSE PANEL A (IN LEFT PLENUM CHAMBER E-BOX) FUSE PANEL B (LEFT END OF DASH) GRN WIRE GRN/WHT WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT AT ALL TIMES SECOND SPEED COOLANT FAN FUSE HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT LEFT FOOTWELL VENT TEMPERATURE SENSOR (LOWER LEFT SIDE OF HVAC UNIT) NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE OUTSIDE AIR TEMPERATURE SENSOR REAR CENTER AIR VENT ILLUMINATION BULB RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOOTWELL VENT TEMPERATURE SENSOR (RIGHT SIDE OF HVAC ASSEMBLY) SYSTEM TERMINAL 30 WIRE JUNCTION (IN CENTER PLENUM CHAMBER) VIO WIRE VIO/WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/WHT WIRE

A/C COMPRESSOR REGULATOR VALVE (REAR OF COMPRESSOR) BLK/RED WIRE BLK/YEL WIRE BLU/BRN WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE CHARGE AIR COOLING PUMP (IN LEFT FRONT WHEELWELL) CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM COOLANT FAN CONTROL (FC) MODULE (ON COOLANT FAN) COOLANT FAN CONTROL (FC) MODULE 2 (ON COOLANT FAN 2) COOLANT FAN FUSE ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENGINE) FUSE FUSE PANEL A FUSE (IN LEFT PLENUM CHAMBER E-BOX) GRN/RED WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES SECOND SPEED COOLANT FAN FUSE HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT VENT POSITION SENSOR (IN LEFT SIDE VENT) NCA WIRE ORG/BLK WIRE ORG/BRN WIRE OUTSIDE AIR TEMPERATURE SENSOR RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT VENT POSITION SENSOR (IN RIGHT SIDE VENT) TERMINAL 30 WIRE JUNCTION (IN CENTER PLENUM CHAMBER) YEL WIRE

BRN WIRE BRN/GRN WIRE CHARGE AIR COOLING PUMP (IN LEFT FRONT WHEELWELL) COMPUTER DATA LINES SYSTEM COOLANT FAN CONTROL MODULE (ON COOLANT FAN) COOLANT FAN CONTROL MODULE 2 (ON COOLANT FAN 2) COOLANT FAN FUSE ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENGINE) FUSE FUSE PANEL A (IN LEFT PLENUM CHAMBER E-BOX) HOT AT ALL TIMES HOT AT ALL TIMES COOLANT SECOND SPEED FAN HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED HOT W/ MOTRONIC ENGINE CONTROL MODULE RELAY ENERGIZED NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE TERMINAL 30 WIRE JUNCTION (IN CENTER PLENUM CHAMBER) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) YEL WIRE
