Audi A7 I (2010-2014) front passenger's exterior rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.front passenger's exterior rearview mirror, which is found in the car Audi A7 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's exterior rearview mirror (1 of 1)
ASSISTANCE)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL STABILIZATION ASSISTANCE BUTTON (W/ LANE ASSIST)
DRIVER'S EXTERIOR REARVIEW MIRROR
FRONT PASSENGER'S EXTERIOR REARVIEW MIRROR
FUSE 8
FUSE CARRIER 4
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRY/BLU WIRE
HOT W/ POWER SUPPLY (TERMINAL 15) RELAY 2 ENERGIZED
LANE CHANGE
LANE CHANGE ASSISTANCE BUTTON
LANE CHANGE ASSISTANCE CONTROL MODULE (BEHIND RIGHT END OF REAR BUMPER TRIM)
LANE CHANGE ASSISTANCE CONTROL MODULE 2 (BEHIND LEFT END OF REAR BUMPER TRIM)
LANE CHANGE ASSISTANCE INDICATOR LAMP
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
STEERING COLUMN ELECTRONICS CONTROL MODULE (TOP OF STEERING COLUMN)
SWITCH ILLUMINATION BULB
VIO/YEL WIRE
WARNING LAMP
YEL/BLU WIRE
Go to component: -> Lane change assistance circuit -> FRONT PASSENGER'S EXTERIOR REARVIEW MIRROR
