Audi A7 I (2010-2014) driver power seat adjustment circuit breaker 1 Wiring diagram
This page shows the only wiring diagram for the component.driver power seat adjustment circuit breaker 1, which is found in the car Audi A7 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver power seat adjustment circuit breaker 1 (1 of 1)
BLK/BRN WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST HEATING ELEMENT
DRIVER DOOR CONTROL MODULE
DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER SEAT BACKREST BLOWER FAN
DRIVER SEAT BACKREST BLOWER FAN 2
DRIVER SEAT CUSHION BLOWER FAN
DRIVER SEAT CUSHION BLOWER FAN 2
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER MEMORY SEAT CONTROL MODULE
FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
FRONT PASSENGER SEAT BACKREST BLOWER FAN
FRONT PASSENGER SEAT BACKREST BLOWER FAN 2
FRONT PASSENGER SEAT CUSHION BLOWER FAN
FRONT PASSENGER SEAT CUSHION BLOWER FAN 2
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRY/BRN WIRE
HEATING ELEMENT
HOT AT ALL TIMES
LEFT FRONT SEAT HEATER
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT HEATER
SEAT TEMPERATURE SENSOR
SIDE BOLSTER HEATER
TEMPERATURE SENSOR
YEL WIRE
YEL/WHT WIRE
Go to component: -> Heated seats circuit, w/ memory seats w/ ventilation -> DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
