Audi A7 I (2010-2014) driver door contact switch Wiring diagrams

This page contains all the electrical diagrams for the component. driver door contact switch, in which he is found in the car Audi A7 I (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver door contact switch (1 of 2)

Wiring diagram driver door contact switch for Audi A7 I (2010-2014)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CENTRAL LOCKING SAFE INDICATOR LAMP COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DRIVER DOOR CLOSING ASSIST MOTOR DRIVER DOOR CONTACT SWITCH DRIVER DOOR CONTROL MODULE (IN DRIVER FRONT DOOR) DRIVER INTERIOR LOCKING SWITCH DRIVER LOCK CYLINDER (UNDER CONTACT DRIVER'S SWITCH SEAT) FUSE CARRIER FUSE FUSE PANEL B (LEFT END OF DASH) GRN RED/ WIRE GRN/BLU WIRE GRY WIRE GRY/GRN WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT FRONT CENTRAL LOCKING SYSTEM ACTUATOR ORG/BRN WIRE ORG/GRN WIRE RED GRN/ WIRE RED/GRN WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE W/ DOOR CLOSING AID W/O DOOR CLOSING AID

Go to component: -> Anti-theft circuit (1 of 5) -> DRIVER DOOR CONTACT SWITCH

Wiring diagram driver door contact switch (2 of 2)

Wiring diagram driver door contact switch for Audi A7 I (2010-2014)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CENTRAL LOCKING SAFE INDICATOR LAMP COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DRIVER DOOR CLOSING ASSIST MOTOR DRIVER DOOR CONTACT SWITCH DRIVER DOOR CONTROL MODULE (IN DRIVER FRONT DOOR) DRIVER INTERIOR LOCKING SWITCH DRIVER LOCK CYLINDER (UNDER CONTACT DRIVER'S SWITCH SEAT) FUSE CARRIER FUSE FUSE PANEL B (LEFT END OF DASH) GRN RED/ WIRE GRN/BLU WIRE GRY WIRE GRY/GRN WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT FRONT CENTRAL LOCKING SYSTEM ACTUATOR ORG/BRN WIRE ORG/GRN WIRE RED GRN/ WIRE RED/GRN WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE W/ DOOR CLOSING AID W/O DOOR CLOSING AID

Go to component: -> Power door locks circuit (1 of 5) -> DRIVER DOOR CONTACT SWITCH
