Audi A7 I (2010-2014) cooling circuit solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.cooling circuit solenoid valve, which is found in the car Audi A7 I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cooling circuit solenoid valve (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CHARGE AIR COOLING PUMP (IN LEFT FRONT WHEELWELL)
CONTROL VALVE CONTROL UNIT (REAR OF SUPERCHARGER)
COOLING CIRCUIT SOLENOID VALVE
FUSE 14
FUSE 17
FUSE 4
FUSE 5
FUSE PANEL A
FUSE PANEL A (IN LEFT PLENUM CHAMBER E-BOX)
GRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES MAIN FUSE CARRIER SAFETY (IN LUGGAGE FUSE COMPT ON BATTERY)
MOTRONIC ENGINE CONTROL MODULE (ECM) POWER SUPPLY RELAY
OIL PRESSURE SWITCH (ON OIL FILTER HOUSING)
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
REDUCED OIL PRESSURE SWITCH (ON OIL FILTER HOUSING BASE)
SECONDARY AIR INJECTION (AIR) SOLENOID VALVE (REAR OF ENGINE)
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l sc (2 of 8) -> COOLING CIRCUIT SOLENOID VALVE
