Audi A6 C8 facelift (2022-2024) roof antenna Wiring diagrams
This page contains all the electrical diagrams for the component. roof antenna, in which he is found in the car Audi A6 C8 facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram roof antenna (1 of 12)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FUSE 7
FUSE PANEL M
GPS ANTENNA
GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
PNK WIRE
RED/GRY WIRE
RIGHT REAR BUMPER EMERGENCY CALL MODULE ANTENNA
ROOF ANTENNA
SUPPLEMENTAL RESTRAINTS SYSTEM
VEHICLE INTERIOR COMMUNICATION ANTENNA
VIO/GRY WIRE
W/ VEHICLE POSITIONING SYSTEM, W/O NAVIGATION SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Emergency call circuit, w/ connect plus (1 of 2) -> ROOF ANTENNA
Wiring diagram roof antenna (2 of 12)
AIR BAG CONTROL MODULE
BLK WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE (BELOW CENTER OF REAR SEAT)
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD
FRONT PASSENGER SEAT COUPLING POINT
FRONT ROOF MODULE
FUSE 7
FUSE 8
FUSE PANEL B
GPS ANTENNA
GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
NCA WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT REAR BUMPER EMERGENCY CALL MODULE ANTENNA
ROAD SIDE ASSISTANCE BUTTON
ROOF ANTENNA
TELEMATICS EMERGENCY BATTERY
VIO/GRY WIRE
VIO/RED WIRE
W/ MOBILE ONLINE SERVICES
W/ POWER MEMORY FRONT SEATS
WHT WIRE
YEL WIRE
Go to component -> Emergency call circuit, w/o connect plus (2 of 2) -> ROOF ANTENNA
Wiring diagram roof antenna (3 of 12)
ANTENNA AMPLIFIER 2
AUXILIARY DISPLAY CONTROL HEAD 1
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
FUSE 2
FUSE 5
FUSE PANEL M
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH)
LEFT FRONT TREBLE SPEAKER
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT TREBLE SPEAKER
ROOF ANTENNA
ROOF ANTENNA CONTROL MODULE
SATELLITE ANTENNA
WHT/BLU WIRE
WHT/YEL WIRE
WIRELESS CONTROL HEAD 1
Go to component -> Navigation circuit, w/ amplifier & bang & olufsen sound (4 of 6) -> ROOF ANTENNA
Wiring diagram roof antenna (4 of 12)
ANTENNA
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
AUXILIARY DISPLAY CONTROL HEAD 1 WIRELESS CONTROL HEAD 1
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE 5
FUSE PANEL J
FUSE PANEL M
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH)
INSTRUMENT CLUSTER SYSTEM
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
ROOF ANTENNA
ROOF ANTENNA CONTROL MODULE
SATELLITE ANTENNA
SOUND SYSTEMS
VIO WIRE
Go to component -> Navigation circuit, w/ amplifier w/o bang & olufsen sound (3 of 6) -> ROOF ANTENNA
Wiring diagram roof antenna (5 of 12)
ANTENNA
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CELLULAR TELEPHONE AMPLIFIER
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FUSE 6
FUSE PANEL F
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH)
INSTRUMENT CLUSTER SYSTEM
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
ROOF ANTENNA
ROOF ANTENNA CONTROL MODULE
SATELLITE ANTENNA
SOUND SYSTEMS
VIO WIRE
Go to component -> Navigation circuit, w/o amplifier (2 of 4) -> ROOF ANTENNA
Wiring diagram roof antenna (6 of 12)
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
CENTER CONSOLE SWITCH MODULE 1
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
COUPLING POINT 2 IN LEFT FRONT DOOR
COUPLING POINT 2 IN RIGHT FRONT DOOR
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FRONT PERIPHERAL CAMERA
FUSE 2
FUSE 5
FUSE 9
FUSE PANEL B
FUSE PANEL F
FUSE PANEL M
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
INSTRUMENT CLUSTER CONTROL MODULE
LEFT FRONT BUMPER COUPLING POINT
LEFT FRONT DOOR COUPLING POINT
LEFT PERIPHERAL CAMERA
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
REAR PERIPHERAL CAMERA
RED/BLK WIRE
RED/GRN WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT PERIPHERAL CAMERA
ROOF ANTENNA
WHT/BLK WIRE
Go to component -> Peripheral camera circuit -> ROOF ANTENNA
Wiring diagram roof antenna (7 of 12)
ABS CONTROL MODULE
ACTIVE STEERING CONTROL MODULE
AIR BAG CONTROL MODULE
ALL- WHEEL DRIVE CONTROL MODULE
AUTOMATIC TRANSMISSION COUPLING POINT
BLK/VIO WIRE
BLU/YEL WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRAKE BOOSTER CONTROL MODULE
COMFORT SYSTEM CENTRAL CONTROL MODULE
DIFFERENTIAL LOCK CONTROL MODULE
DRIVETRAIN CONTROL MODULE
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
ENGINE/ MOTOR CONTROL MODULE
FRESH AIR BLOWER CONTROL MODULE
FROM DATA BUS ON BOARD DIAGNOSTIC INTERFACE (DIAGRAM 4 OF 9)
FROM FUSE PANEL D (DIAGRAM 3 OF 9)
FROM FUSE PANEL M (DIAGRAM 5 OF 9)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL J
N/A
NOT USED
POWER STEERING CONTROL MODULE
REAR A/C DISPLAY CONTROL HEAD
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
ROOF ANTENNA
STARTER RELAY 1 RELAY & FUSE CARRIER 1
TO BOTTOM COUPLING POINT ON LEFT A-PILLAR (DIAGRAM 1 OF 9)
TRANSMISSION ELECTRIC PUMP 2
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
W/O CLIMATRONIC
WINDSHIELD WASHER PUMP CONTROL MODULE
Go to component -> Power distribution circuit (6 of 9) -> ROOF ANTENNA
Wiring diagram roof antenna (8 of 12)
ANTENNA AMPLIFIER 2
AUXILIARY DISPLAY CONTROL HEAD 1
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
FUSE 2
FUSE 5
FUSE PANEL M
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH)
LEFT FRONT TREBLE SPEAKER
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT TREBLE SPEAKER
ROOF ANTENNA
ROOF ANTENNA CONTROL MODULE
SATELLITE ANTENNA
WHT/BLU WIRE
WHT/YEL WIRE
WIRELESS CONTROL HEAD 1
Go to component -> Radio circuit, w/ amplifier & bang & olufsen sound (4 of 6) -> ROOF ANTENNA
Wiring diagram roof antenna (9 of 12)
ANTENNA
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
AUXILIARY DISPLAY CONTROL HEAD 1 WIRELESS CONTROL HEAD 1
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE 5
FUSE PANEL J
FUSE PANEL M
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH)
INSTRUMENT CLUSTER SYSTEM
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
ROOF ANTENNA
ROOF ANTENNA CONTROL MODULE
SATELLITE ANTENNA
SOUND SYSTEMS
VIO WIRE
Go to component -> Radio circuit, w/ amplifier w/o bang & olufsen sound (3 of 6) -> ROOF ANTENNA
Wiring diagram roof antenna (10 of 12)
ANTENNA
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CELLULAR TELEPHONE AMPLIFIER
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FUSE 6
FUSE PANEL F
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH)
INSTRUMENT CLUSTER SYSTEM
MOST DATA BUS CIRCUIT
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
ROOF ANTENNA
ROOF ANTENNA CONTROL MODULE
SATELLITE ANTENNA
SOUND SYSTEMS
VIO WIRE
Go to component -> Radio circuit, w/o amplifier (2 of 4) -> ROOF ANTENNA
