Audi A6 C8 facelift (2022-2024) charge air cooling pump Wiring diagrams
This page contains all the electrical diagrams for the component. charge air cooling pump, in which he is found in the car Audi A6 C8 facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
charge air cooling pump wiring diagram (1 of 2)
3.0L TURBO HYBRID, 2.9L TURBO HYBRID
4.0L TURBO HYBRID
ADAPTIVE CRUISE CONTROL MODULE
ANTENNA AMPLIFIER
BLK WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRAKE BOOSTER CONTROL MODULE
BRN WIRE
CHARGE AIR COOLING PUMP
COOLANT RECIRCULATION PUMP
ELECTRIC COMPRESSOR CONTROL MODULE
ENGINE HOOD CONTACT SWITCH
EXCEPT 2.0L TURBO
FROM ENGINE/MOTOR CONTROL MODULE (DIAGRAM 3 OF 11)
FROM LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT (DIAGRAM 3 OF 11)
HIGH PRESSURE SENSOR
HIGH TONE HORN
HIGH-MOUNTED BRAKE LAMP SUPPRESSOR
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION COIL 6 W/ POWER OUTPUT STAGE
IGNITION COIL 7 W/ POWER OUTPUT STAGE
IGNITION COIL 8 W/ POWER OUTPUT STAGE
INFORMATION ELECTRONICS CONTROL MODULE 1
LASER DISTANCE REGULATION CONTROL MODULE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT FRONT HEADLAMP
LEFT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE
LOW TONE HORN
REAR WINDOW
REAR WINDOW DEFOGGER SUPPRESSOR 2
RIGHT FRONT HEADLAMP
RIGHT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE
STARTER GENERATOR
TERMINAL 30 WIRE JUNCTION SUPPRESSOR
Go to component -> Ground distribution circuit (2 of 11) -> CHARGE AIR COOLING PUMP
charge air cooling pump wiring diagram (2 of 2)
AFTER-RUN COOLANT PUMP
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRAKE PEDAL POSITION SENSOR
CAMSHAFT ADJUSTMENT VALVE 1
CAMSHAFT ADJUSTMENT VALVE 2
CHARGE AIR COOLING PUMP
COOLANT RECIRCULATION PUMP
CRANKCASE VENTILATION THERMAL RESISTOR 2
CRANKCASE VENTILATION VALVE
CYLINDER 5 INTAKE CAM ACTUATOR 1
CYLINDER 6 INTAKE CAM ACTUATOR 1
ELECTRIC COMPRESSOR CONTROL MODULE
ELECTRICAL COMPRESSOR BYPASS DOOR VALVE
ENGINE COMPONENT POWER SUPPLY RELAY
ENGINE COUPLING POINT 2
ENGINE/MOTOR CONTROL MODULE
EXHAUST CAMSHAFT ADJUSTMENT VALVE 1
EXHAUST CAMSHAFT ADJUSTMENT VALVE 2
EXHAUST DOOR CONTROL UNIT
EXHAUST DOOR CONTROL UNIT 2
FROM MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY (DIAGRAM 7 OF 9)
FUEL PUMP CONTROL MODULE
FUEL TANK LEAK DETECTION MODULE
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL A
GRY/RED WIRE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
MAP CONTROLLED ENGINE COOLING THERMOSTAT
OIL LEVEL THERMAL SENSOR
OXYGEN SENSOR 1 (BEFORE CATALYTIC CONVERTER)
OXYGEN SENSOR 1 AFTER CATALYTIC CONVERTER
PISTON COOLING NOZZLE CONTROL VALVE
POSITIVE CRANKCASE VENTILATION HEATING ELEMENT
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 2
STARTER GENERATOR
TO COOLANT RECIRCULATION PUMP (DIAGRAM 8 OF 9)
TRANSMISSION FLUID COOLING PUMP
VIO/RED WIRE
WASTEGATE BYPASS REGULATOR VALVE
WHT/GRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (9 of 9) -> CHARGE AIR COOLING PUMP
