Audi A6 C8 facelift (2022-2024) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi A6 C8 facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
brn wiring diagram (131 of 201)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
EXTERIOR LAMPS CIRCUIT
FUSE 14
FUSE PANEL M
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT BACKUP LAMP
LEFT BRAKE LAMP/TURN SIGNAL LAMP 2
LEFT TAIL LAMP 2
ORG/BRN WIRE
PNK WIRE
RED/YEL WIRE
RIGHT BACKUP LAMP
RIGHT BRAKE LAMP/TURN SIGNAL LAMP 2
RIGHT TAIL LAMP 2
TRANSMISSION CONTROL MODULE
VIO WIRE
VIO/WHT WIRE
Go to component -> Backup lamps circuit -> BRN WIRE
brn wiring diagram (132 of 201)
AUTOMATIC HIGH BEAM BUTTON
BRN WIRE
CENTER INSTRUMENT PANEL SWITCH MODULE
COMPUTER DATA LINES SYSTEM
EMERGENCY FLASHER BUTTON
EMERGENCY FLASHER INDICATOR
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 4
FUSE 5
FUSE PANEL F
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/RED WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LIGHT SWITCH
ORG/BRN WIRE
PNK WIRE
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED/VIO WIRE
RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
RIGHT FRONT HEADLAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP 2-PIN CONNECTOR
RIGHT HEADLAMP CURRENT CODING RESISTANCE 1
RIGHT HEADLAMP TEMPERATURE SENSOR 1
RIGHT HEADLAMP TEMPERATURE SENSOR 2
RIGHT LED HEADLAMP POWER OUTPUT MODULE 1
RIGHT STATIONARY CORNERING LAMP
STEERING COLUMN ELECTRONICS CONTROL MODULE
TURN SIGNAL SWITCH
VIO/WHT WIRE
WHT/RED WIRE
Go to component -> Exterior lamps circuit, w/ matrix beam (2 of 4) -> BRN WIRE
brn wiring diagram (133 of 201)
ABS CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BRAKE LAMP SWITCH
BRAKE PEDAL POSITION SENSOR
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
ENGINE/MOTOR CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 5
FUSE PANEL A
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
ORG/BRN WIRE
RIGHT BACKUP LAMP
RIGHT BRAKE LAMP/TURN SIGNAL LAMP
RIGHT BRAKE LAMP/TURN SIGNAL LAMP 2
RIGHT TAIL LAMP
RIGHT TAIL LAMP 2
TURN SIGNAL LAMP
VIO/RED WIRE
VIO/WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, w/ matrix beam (4 of 4) -> BRN WIRE
brn wiring diagram (134 of 201)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
DRIVER'S FRONT DOOR)
FUSE 3
FUSE 9
FUSE PANEL D
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT DYNAMIC TURN SIGNAL
LEFT FRONT HEADLAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP 16-PIN CONNECTOR
LEFT HEADLAMP 24-PIN CONNECTOR
LEFT HEADLAMP TEMPERATURE SENSOR 4
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT MATRIX HEADLAMP POWER OUTPUT MODULE
LEFT STATIONARY CORNERING LAMP
LEFT TURN SIGNAL INDICATOR
ORG/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT EMERGENCY FLASHER INDICATOR
TURN SIGNAL LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, w/ multiple matrix beam (1 of 4) -> BRN WIRE
brn wiring diagram (135 of 201)
AUTOMATIC HIGH BEAM BUTTON
BRN WIRE
CENTER INSTRUMENT PANEL SWITCH MODULE
COMPUTER DATA LINES SYSTEM
EMERGENCY FLASHER BUTTON
EMERGENCY FLASHER INDICATOR
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 4
FUSE 5
FUSE PANEL F
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/RED WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LIGHT SWITCH
ORG/BRN WIRE
PNK WIRE
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED/VIO WIRE
RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
RIGHT FRONT DYNAMIC TURN SIGNAL
RIGHT FRONT HEADLAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP 16-PIN CONNECTOR
RIGHT HEADLAMP 24-PIN CONNECTOR
RIGHT HEADLAMP TEMPERATURE SENSOR 4
RIGHT LED HEADLAMP POWER OUTPUT MODULE 1
RIGHT MATRIX HEADLAMP POWER OUTPUT MODULE
RIGHT STATIONARY CORNERING LAMP
STEERING COLUMN ELECTRONICS CONTROL MODULE
TURN SIGNAL SWITCH
VIO/WHT WIRE
WHT/RED WIRE
Go to component -> Exterior lamps circuit, w/ multiple matrix beam (2 of 4) -> BRN WIRE
brn wiring diagram (136 of 201)
ABS CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BRAKE LAMP SWITCH
BRAKE PEDAL POSITION SENSOR
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
ENGINE/MOTOR CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 5
FUSE PANEL A
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
ORG/BRN WIRE
RIGHT BACKUP LAMP
RIGHT BRAKE LAMP/TURN SIGNAL LAMP
RIGHT BRAKE LAMP/TURN SIGNAL LAMP 2
RIGHT TAIL LAMP
RIGHT TAIL LAMP 2
TURN SIGNAL LAMP
VIO/RED WIRE
VIO/WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, w/ multiple matrix beam (4 of 4) -> BRN WIRE
brn wiring diagram (137 of 201)
AUTOMATIC HIGH BEAM BUTTON
BRN WIRE
CENTER INSTRUMENT PANEL SWITCH MODULE
COMPUTER DATA LINES SYSTEM
EMERGENCY FLASHER BUTTON
EMERGENCY FLASHER INDICATOR
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 4
FUSE 5
FUSE PANEL F
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/RED WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LIGHT SWITCH
ORG/BRN WIRE
PNK WIRE
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED/VIO WIRE
RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
RIGHT FRONT HEADLAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP 8-PIN CONNECTOR
RIGHT HEADLAMP CURRENT CODING RESISTANCE 1
RIGHT HEADLAMP CURRENT CODING RESISTANCE 3
RIGHT HEADLAMP TEMPERATURE SENSOR 1
RIGHT HEADLAMP TEMPERATURE SENSOR 3
RIGHT LED HEADLAMP POWER OUTPUT MODULE 1
RIGHT STATIONARY CORNERING LAMP
STEERING COLUMN ELECTRONICS CONTROL MODULE
TURN SIGNAL SWITCH
VIO/WHT WIRE
WHT/RED WIRE
Go to component -> Exterior lamps circuit, w/o matrix beam (2 of 4) -> BRN WIRE
brn wiring diagram (138 of 201)
ABS CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BRAKE LAMP SWITCH
BRAKE PEDAL POSITION SENSOR
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
ENGINE/MOTOR CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 5
FUSE PANEL A
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
ORG/BRN WIRE
RIGHT BACKUP LAMP
RIGHT BRAKE LAMP/TURN SIGNAL LAMP
RIGHT BRAKE LAMP/TURN SIGNAL LAMP 2
RIGHT TAIL LAMP
RIGHT TAIL LAMP 2
TURN SIGNAL LAMP
VIO/RED WIRE
VIO/WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, w/o matrix beam (4 of 4) -> BRN WIRE
brn wiring diagram (139 of 201)
AIR BAG CONTROL MODULE
AIR BAG INDICATOR LAMP
BATTERY INTERRUPT IGNITER
BATTERY MONITORING CONTROL MODULE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER HEAD CURTAIN AIR BAG IGNITER
DRIVER SEAT BELT SWITCH
DRIVER SEAT COUPLING POINT
DRIVER SEAT POSITION SENSOR
ENGINE CONTROLS SYSTEM
FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER
FUSE 10
FUSE 3
FUSE 4
FUSE 7
FUSE PANEL F
FUSE PANEL H
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Supplemental restraints circuit (1 of 5) -> BRN WIRE
brn wiring diagram (140 of 201)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER AIR BAG IGNITER
DRIVER AIR BAG RELEASE VALVE IGNITER
DRIVER BELT FORCE LIMITER
DRIVER KNEE AIR BAG IGNITER
DRIVER SEAT BELT TENSIONER IGNITER 1
DRIVER SIDE REAR SEAT OCCUPANT DETECTION SENSOR
FRONT PASSENGER AIR BAG UNIT (RIGHT SIDE OF DASH)
FRONT PASSENGER BELT FORCE LIMITER
FRONT PASSENGER KNEE AIR BAG IGNITER
FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1
GRN WIRE
GRY WIRE
HORNS SYSTEM
IGNITER 1
IGNITER 2
LEFT FRONT SEAT BELT
LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE
ORG/BRN WIRE
PASSENGER SIDE REAR SEAT OCCUPANT DETECTION SENSOR
REAR CENTER SEAT OCCUPANT DETECTION SENSOR
REAR SEAT COUPLING POINT
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RELEASE VALVE IGNITER
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE
STEERING COLUMN ELECTRONICS CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (4 of 5) -> BRN WIRE
