Front heated seats circuit, w/ ventilation for Audi A6 C8 (2018-2023)

BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BOLSTER HEATER DRIVER SEAT COUPLING POINT FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 1 FUSE 10 FUSE PANEL D (LEFT KICK PANEL) FUSE PANEL E (LEFT KICK PANEL) GRN WIRE HOT AT ALL TIMES LEFT FRONT SEAT TEMPERATURE SENSOR DRIVER SEAT HEATING ELEMENT LEFT SEAT HEATING BUTTON ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT SEAT HEATING BUTTON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

BLK/YEL WIRE BRN WIRE BRN/YEL WIRE COUPLING STATION IN RIGHT FRONT SEAT DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT COUPLING POINT DRIVER SEAT CUSHION BLOWER FAN FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER SEAT BACKREST BLOWER FAN FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT BOLSTER HEATER FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER SEAT CUSHION BLOWER FAN FRONT PASSENGER SEAT HEATING ELEMENT FRONT PASSENGER SEAT TEMPERATURE SENSOR GRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE RED/YEL WIRE SUPPLEMENTAL RESTRAINTS SYSTEM VIO/BLU WIRE VIO/WHT WIRE W/ MEMORY W/O MEMORY WHT WIRE WHT/VIO WIRE YEL WIRE
