Navigation circuit, w/ amplifier & bang & olufsen sound for Audi A6 C8 (2018-2023)

BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/YEL WIRE DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE FRONT ROOF MODULE MICROPHONE UNIT GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES INTERIOR MICROPHONE LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT DOOR SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT FRONT TREBLE SPEAKER, MOTOR LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY & FUSE CARRIER 4 RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT DOOR SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT FRONT TREBLE SPEAKER, MOTOR RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT SOUND SYSTEMS SUBWOOFER VIO WIRE VIO/BLU WIRE VIO/GRN WIRE W/ EMERGENCY CALL MODULE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE

BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COUPLING POINT IN LEFT REAR DOOR COUPLING POINT IN RIGHT REAR DOOR DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE LEFT EFFECTS SPEAKER LEFT FRONT MIDRANGE SPEAKER 2 LEFT REAR DOOR COUPLING POINT LEFT REAR MIDRANGE SPEAKER 2 LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT EFFECTS SPEAKER RIGHT FRONT MIDRANGE SPEAKER 2 RIGHT REAR DOOR COUPLING POINT RIGHT REAR MIDRANGE SPEAKER 2 RIGHT REAR TREBLE SPEAKER SOUND SYSTEMS VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE

ANTENNA ANTENNA AMPLIFIER (RIGHT "C" PILLAR) BLK WIRE BLK/GRY WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE CELLULAR TELEPHONE AMPLIFIER CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER SPEAKER CENTER SPEAKER 2 COMPUTER DATA LINES SYSTEM DRIVER VOLUME CONTROL FUSE 6 FUSE PANEL F GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH) MOST DATA BUS CIRCUIT NCA WIRE ORG/BRN WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE SOUND SYSTEMS VIO WIRE WHT/BLU WIRE WHT/GRN WIRE

ANTENNA AMPLIFIER 2 (TO OF LEFT "D" PILLAR) AUXILIARY DISPLAY CONTROL HEAD 1 BLK WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA FUSE 2 FUSE 5 FUSE PANEL M GPS ANTENNA HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH) LTE ANTENNA 1 NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE RED/VIO WIRE RED/YEL WIRE ROOF ANTENNA ROOF ANTENNA CONTROL MODULE SATELLITE ANTENNA W/ GPS ANTENNA SPLITTER W/O GPS ANTENNA SPLITTER WIRELESS CONTROL HEAD 1

ACCESS START AUTHORIZATION BUTTON AUDIO MUSIC INTERFACE BLK WIRE BLU WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL DATA BUS ON BOARD DIAGNOSTIC INTERFACE (W/ VEHICLE EMERGENCY SYSTEM) FRONT ROOF MODULE MICROPHONE UNIT FUSE 2 FUSE 3 FUSE PANEL G GRN WIRE GRY/GRN WIRE HOT AT ALL TIMES LEFT FRONT MICROPHONE NCA WIRE ORG/ WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FRONT MICROPHONE USB CONNECTION 1 USB DISTRIBUTOR (REAR OF CENTER CONSOLE) W/ EXTERNAL AUDIO SOURCE CONNECTION YEL/GRN WIRE

BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD FRONT INFORMATION DISPLAY CONTROL HEAD 2 FUSE 5 FUSE 7 FUSE 8 FUSE PANEL B FUSE PANEL F GRN WIRE GRY/GRN WIRE HIGH PLUS RADIO HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE LTE ANTENNA 1 LTE ANTENNA 2 MEDIUM PLUS RADIO MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NCA WIRE ORG/ WIRE ORG/BRN WIRE PNK WIRE REAR CAMERA CIRCUIT RED WIRE RED/WHT WIRE RED/YEL WIRE SOUND SYSTEMS VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VEHICLE INTERIOR COMMUNICATION ANTENNA VIO/GRY WIRE W/ EMERGENCY CALL MODULE W/O EMERGENCY CALL MODULE WHT WIRE
