Audi A6 C8 (2018-2023) w/ vehicle positioning system, w/o navigation system Wiring diagram
This page shows the only wiring diagram for the component.w/ vehicle positioning system, w/o navigation system, which is found in the car Audi A6 C8 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ vehicle positioning system, w/o navigation system (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FUSE 7
FUSE PANEL M
GPS ANTENNA
GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
PNK WIRE
RED/GRY WIRE
RIGHT REAR BUMPER EMERGENCY CALL MODULE ANTENNA
ROOF ANTENNA
SUPPLEMENTAL RESTRAINTS SYSTEM
VEHICLE INTERIOR COMMUNICATION ANTENNA
VIO/GRY WIRE
W/ VEHICLE POSITIONING SYSTEM, W/O NAVIGATION SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Emergency call circuit, w/ connect plus (1 of 2) -> W/ VEHICLE POSITIONING SYSTEM, W/O NAVIGATION SYSTEM
