Audi A6 C8 (2018-2023) w/ power memory front seats Wiring diagram
This page shows the only wiring diagram for the component.w/ power memory front seats, which is found in the car Audi A6 C8 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ power memory front seats (1 of 1)
AIR BAG CONTROL MODULE
BLK WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE (BELOW CENTER OF REAR SEAT)
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD
FRONT PASSENGER SEAT COUPLING POINT
FRONT ROOF MODULE
FUSE 7
FUSE 8
FUSE PANEL B
GPS ANTENNA
GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
NCA WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT REAR BUMPER EMERGENCY CALL MODULE ANTENNA
ROAD SIDE ASSISTANCE BUTTON
ROOF ANTENNA
TELEMATICS EMERGENCY BATTERY
VIO/GRY WIRE
VIO/RED WIRE
W/ MOBILE ONLINE SERVICES
W/ POWER MEMORY FRONT SEATS
WHT WIRE
YEL WIRE
Go to component: -> Emergency call circuit, w/o connect plus (2 of 2) -> W/ POWER MEMORY FRONT SEATS
