Audi A6 C8 (2018-2023) telematics emergency battery Wiring diagrams

This page contains all the electrical diagrams for the component. telematics emergency battery, in which he is found in the car Audi A6 C8 (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram telematics emergency battery (1 of 2)

Wiring diagram telematics emergency battery for Audi A6 C8 (2018-2023)

Get access

BLK WIRE BLK/VIO WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL DATA BUS ON BOARD DIAGNOSTIC INTERFACE EMERGENCY CALL MODULE SPEAKER EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT COUPLING POINT GRN WIRE GRY/YEL WIRE LTE ANTENNA 1 (W/ MOBILE ONLINE SERVICE) NCA WIRE ORG/BRN WIRE ORG/VIO WIRE PNK WIRE RIGHT REAR BUMPER EMERGENCY CALL MODULE ANTENNA ROOF ANTENNA TELEMATICS EMERGENCY BATTERY VIO/GRY WIRE W/ EMERGENCY CALL MODULE W/O EMERGENCY CALL MODULE WHT WIRE YEL WIRE

Go to component: -> Computer data lines circuit (9 of 9) -> TELEMATICS EMERGENCY BATTERY

Wiring diagram telematics emergency battery (2 of 2)

Wiring diagram telematics emergency battery for Audi A6 C8 (2018-2023)

Get access

AIR BAG CONTROL MODULE BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE (BELOW CENTER OF REAR SEAT) EMERGENCY CALL BUTTON EMERGENCY CALL MODULE ANTENNA 2 EMERGENCY CALL MODULE SPEAKER FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT COUPLING POINT FRONT ROOF MODULE FUSE 7 FUSE 8 FUSE PANEL B GPS ANTENNA GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES NCA WIRE RED/BLK WIRE RED/BLU WIRE RIGHT REAR BUMPER EMERGENCY CALL MODULE ANTENNA ROAD SIDE ASSISTANCE BUTTON ROOF ANTENNA TELEMATICS EMERGENCY BATTERY VIO/GRY WIRE VIO/RED WIRE W/ MOBILE ONLINE SERVICES W/ POWER MEMORY FRONT SEATS WHT WIRE YEL WIRE

Go to component: -> Emergency call circuit, w/o connect plus (2 of 2) -> TELEMATICS EMERGENCY BATTERY
