Audi A6 C8 (2018-2023) structure borne sound control module Wiring diagram
This page shows the only wiring diagram for the component.structure borne sound control module, which is found in the car Audi A6 C8 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram structure borne sound control module (1 of 1)
AUXILIARY DISPLAY CONTROL HEAD 1
AUXILIARY HEATER CONTROL MODULE
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COUPLING POINT ON ROOF
DIGITAL SOUND SYSTEM CONTROL MODULE
ENGINE SOUND GENERATOR CONTROL MODULE
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT INFORMATION DISPLAY CONTROL HEAD 2
FRONT ROOF MODULE
FRONT ROOF MODULE MICROPHONE UNIT
GARAGE DOOR OPENER CONTROL MODULE
GRN WIRE
GRY WIRE
GRY/YEL WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1
INTERIOR REAR VIEW MIRROR
LTE ANTENNA 2
MOBILE DEVICE CHARGER 1
NCA WIRE
NIGHT VISION SYSTEM CONTROL MODULE
ORG/BRN WIRE
PNK WIRE
RED WIRE
STRUCTURE BORNE SOUND CONTROL MODULE
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
W/ DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
W/ EMERGENCY CALL MODULE
W/O DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
W/O EMERGENCY CALL MODULE
WHT WIRE
Go to component: -> Computer data lines circuit (8 of 9) -> STRUCTURE BORNE SOUND CONTROL MODULE
