Audi A6 C8 (2018-2023) pnk Wiring diagrams

ACTIVE STEERING CONTROL MODULE ACTIVE STEERING MOTOR ACTIVE STEERING MOTOR ROTOR POSITION SENSOR ACTIVE STEERING SAFETY LOCK ACTUATOR BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 10 FUSE PANEL C GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES NCA WIRE PNK WIRE PNK/WHT WIRE RED WIRE SUPPLEMENTAL RESTRAINTS SYSTEM WHT WIRE YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

AUTOMATIC TRANSMISSION CONTROL MODULE FUSE AUTOMATIC TRANSMISSION COUPLING POINT AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4 BLK/VIO WIRE BLU/GRY WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVE POSITION SENSOR ENGINE/MOTOR CONTROL MODULE FUSE 12 FUSE 6 FUSE 9 FUSE PANEL C FUSE PANEL F GEAR POSITION DISTANCE SENSOR 1 GEAR POSITION DISTANCE SENSOR 2 GEAR POSITION DISTANCE SENSOR 3 GEAR POSITION DISTANCE SENSOR 4 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HYDRAULIC PRESSURE SENSOR 1 HYDRAULIC PRESSURE SENSOR 2 PNK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RELAY & FUSE CARRIER 2 SOLENOID VALVE 1 SOLENOID VALVE 2 SOLENOID VALVE 3 SOLENOID VALVE 4 SOLENOID VALVE 5 SOLENOID VALVE 6 TEMPERATURE SENSOR (IN CONTROL MODULE) TRANSMISSION CONTROL MODULE (UNDER TRANSMISSION OIL PAN) TRANSMISSION ELECTRIC PUMP 2 TRANSMISSION ELECTRIC PUMP 3 TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP ROTOR POSITION SENSOR TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION FLUID TEMPERATURE SENSOR 2 TRANSMISSION INPUT SPEED SENSOR 1 TRANSMISSION INPUT SPEED SENSOR 2 WHT WIRE WHT/YEL WIRE

4-PIN CONNECTOR IN THE STEERING WHEEL AUTOMATIC TRANSMISSION COUPLING POINT BLU WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM D/S FUSE 9 FUSE PANEL M GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/BRN WIRE PARKING LOCK SOLENOID PNK WIRE RED WIRE RED/GRN WIRE RED/VIO WIRE RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL SEATS SYSTEM SELECTOR LEVER SELECTOR LEVER POSITION SENSOR SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE DISPLAY SHIFT LOCK SOLENOID SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON TRANSVERSE SELECTOR LEVER LOCK SENSOR VIO WIRE WHT/RED WIRE

BATTERY INTERRUPT IGNITER BLK WIRE BLK/VIO WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL POWER STEERING MOTOR FUSE 1 GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE PNK WIRE POWER STEERING CONTROL MODULE RED WIRE RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT STEERING ANGLE SENSOR STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING TORQUE SENSOR YEL WIRE

ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 ACCELERATOR PEDAL MODULE ACTIVE ACCELERATOR PEDAL MOTOR BATTERY INTERRUPT IGNITER BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPONENT POWER SUPPLY RELAY ENGINE/MOTOR CONTROL MODULE FUSE 1 FUSE 2 FUSE 3 GRN WIRE GRN/VIO WIRE GRN/WHT WIRE HOT AT ALL TIMES MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ORG/BRN WIRE PNK WIRE PNK/WHT WIRE RED WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 YEL/BLK WIRE YEL/BLU WIRE
