Audi A6 C8 (2018-2023) passenger side rear central locking system motor Wiring diagrams

This page contains all the electrical diagrams for the component. passenger side rear central locking system motor, in which he is found in the car Audi A6 C8 (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram passenger side rear central locking system motor (1 of 2)

Wiring diagram passenger side rear central locking system motor for Audi A6 C8 (2018-2023)

Get access

BLK/GRN WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BRN WIRE BRN/GRN WIRE DRIVER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR DRIVER SIDE REAR CHILD SAFETY LOCK MOTOR DRIVER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR DRIVER SIDE REAR DOOR CONTACT SWITCH DRIVER SIDE REAR DOOR EMERGENCY UNLOCK SWITCH DRIVER SIDE REAR DOOR LOCK UNIT DRIVER SIDE REAR EXTERIOR DOOR HANDLE SWITCH DRIVER SIDE REAR INTERIOR DOOR HANDLE SWITCH GRY/GRN WIRE GRY/VIO WIRE GRY/YEL WIRE PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR PASSENGER SIDE REAR CHILD SAFETY LOCK MOTOR PASSENGER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR PASSENGER SIDE REAR DOOR CLOSING AID MOTOR PASSENGER SIDE REAR DOOR CONTACT SWITCH PASSENGER SIDE REAR DOOR EMERGENCY UNLOCK SWITCH PASSENGER SIDE REAR DOOR LOCK UNIT PASSENGER SIDE REAR EXTERIOR DOOR HANDLE SWITCH PASSENGER SIDE REAR INTERIOR DOOR HANDLE SWITCH RED WIRE RED/GRN WIRE VIO/BLU WIRE W/ DOOR CLOSING AID W/ SAFE FUNCTION WHT/BLU WIRE

Go to component: -> Anti-theft circuit (4 of 7) -> PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR

Wiring diagram passenger side rear central locking system motor (2 of 2)

Wiring diagram passenger side rear central locking system motor for Audi A6 C8 (2018-2023)

Get access

BLK/GRN WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BRN WIRE BRN/GRN WIRE DRIVER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR DRIVER SIDE REAR CHILD SAFETY LOCK MOTOR DRIVER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR DRIVER SIDE REAR DOOR CONTACT SWITCH DRIVER SIDE REAR DOOR EMERGENCY UNLOCK SWITCH DRIVER SIDE REAR DOOR LOCK UNIT DRIVER SIDE REAR EXTERIOR DOOR HANDLE SWITCH DRIVER SIDE REAR INTERIOR DOOR HANDLE SWITCH GRY/GRN WIRE GRY/VIO WIRE GRY/YEL WIRE PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR PASSENGER SIDE REAR CHILD SAFETY LOCK MOTOR PASSENGER SIDE REAR DOOR CENTRAL LOCKING SAFE MOTOR PASSENGER SIDE REAR DOOR CLOSING AID MOTOR PASSENGER SIDE REAR DOOR CONTACT SWITCH PASSENGER SIDE REAR DOOR EMERGENCY UNLOCK SWITCH PASSENGER SIDE REAR DOOR LOCK UNIT PASSENGER SIDE REAR EXTERIOR DOOR HANDLE SWITCH PASSENGER SIDE REAR INTERIOR DOOR HANDLE SWITCH RED WIRE RED/GRN WIRE VIO/BLU WIRE W/ DOOR CLOSING AID W/ SAFE FUNCTION WHT/BLU WIRE

Go to component: -> Power door locks circuit (4 of 7) -> PASSENGER SIDE REAR CENTRAL LOCKING SYSTEM MOTOR
