Audi A6 C8 (2018-2023) driver seat lumbar support height adjustment motor Wiring diagram

This page shows the only wiring diagram for the component.driver seat lumbar support height adjustment motor, which is found in the car Audi A6 C8 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver seat lumbar support height adjustment motor (1 of 1)

Wiring diagram driver seat lumbar support height adjustment motor for Audi A6 C8 (2018-2023)

Get access

BRN WIRE DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR FRONT PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR GRN WIRE GRY WIRE HOT AT ALL TIMES RED WIRE RELAY & FUSE CARRIER 2 RELAY & FUSE CARRIER 4 W/ SEAT VENTILATION W/O SEAT VENTILATION W/ SPORT SEAT W/O SEAT VENTILATION, SPORT SEAT WHT WIRE YEL WIRE

Go to component: -> Lumbar circuit -> DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
