Audi A6 C8 (2018-2023) driver seat height adjustment motor Wiring diagrams

This page contains all the electrical diagrams for the component. driver seat height adjustment motor, in which he is found in the car Audi A6 C8 (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver seat height adjustment motor (1 of 2)

Wiring diagram driver seat height adjustment motor for Audi A6 C8 (2018-2023)

Get access

BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT SWITCH DRIVER MULTI-CONTOUR SEAT COMPRESSOR DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT COUPLING POINT DRIVER SEAT DEPTH ADJUSTMENT MOTOR DRIVER SEAT DEPTH ADJUSTMENT SENSOR, DRIVER SEAT DEPTH ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SENSOR DRIVER SEAT HEIGHT ADJUSTMENT SENSOR, DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH DRIVER SEAT TILT ADJUSTMENT SENSOR DRIVER SEAT TILT ADJUSTMENT SENSOR, DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT VALVE BLOCK 1 DRIVER SEAT VALVE BLOCK 2 GRN/BRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE SEAT DEPTH ADJUSTMENT SENSOR VIO WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE

Go to component: -> Driver"s memory seat circuit, w/ comfort seats (1 of 2) -> DRIVER SEAT HEIGHT ADJUSTMENT MOTOR

Wiring diagram driver seat height adjustment motor (2 of 2)

Wiring diagram driver seat height adjustment motor for Audi A6 C8 (2018-2023)

Get access

BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT SWITCH DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SENSOR DRIVER SEAT HEIGHT ADJUSTMENT SENSOR, DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH DRIVER SEAT TILT ADJUSTMENT SENSOR DRIVER SEAT TILT ADJUSTMENT SENSOR, DRIVER SEAT ANGLE ADJUSTMENT MOTOR GRN/BRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

Go to component: -> Driver"s memory seat circuit, w/o comfort seats (1 of 2) -> DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
