Audi A6 C8 (2018-2023) driver assistance system control module Wiring diagram
This page shows the only wiring diagram for the component.driver assistance system control module, which is found in the car Audi A6 C8 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver assistance system control module (1 of 1)
BLK/VIO WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
DRIVER ASSISTANCE SYSTEM CONTROL MODULE
DRIVER DOOR CONTROL MODULE
DRIVER SEAT COUPLING POINT
DRIVER'S FRONT DOOR)
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER MEMORY SEAT CONTROL MODULE
FRONT PASSENGER SEAT COUPLING POINT
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT HEADLAMP
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S FRONT DOOR)
PNK WIRE
PNK/WHT WIRE
REAR SUNROOF CONTROL MODULE
RIGHT FRONT DOOR COUPLING POINT
SUNROOF CONTROL MODULE
VIO WIRE
VIO/WHT WIRE
W/ ACTIVE STEERING
W/ LEVEL CONTROL SYSTEM
W/O ACTIVE STEERING
W/O LEVEL CONTROL SYSTEM
Go to component: -> Computer data lines circuit (4 of 9) -> DRIVER ASSISTANCE SYSTEM CONTROL MODULE
