Audi A6 C8 (2018-2023) coupling station in left front seat Wiring diagrams

This page contains all the electrical diagrams for the component. coupling station in left front seat, in which he is found in the car Audi A6 C8 (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram coupling station in left front seat (1 of 4)

Wiring diagram coupling station in left front seat for Audi A6 C8 (2018-2023)

Get access

BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT DRIVER BACKREST HEATING ELEMENT DRIVER HEATED SEAT EXTENSION DRIVER SEAT BOLSTER HEATER DRIVER SEAT COUPLING POINT FUSE 10 FUSE PANEL D (LEFT KICK PANEL) GRN WIRE HOT AT ALL TIMES LEFT FRONT SEAT TEMPERATURE SENSOR DRIVER SEAT HEATING ELEMENT ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE WHT/VIO WIRE WHT/YEL WIRE

Go to component: -> Front heated seats circuit, w/o ventilation w/ sport seats (1 of 2) -> COUPLING STATION IN LEFT FRONT SEAT

Wiring diagram coupling station in left front seat (2 of 4)

Wiring diagram coupling station in left front seat for Audi A6 C8 (2018-2023)

Get access

BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT COUPLING STATION IN RIGHT FRONT SEAT DRIVER BACKREST HEATING ELEMENT DRIVER SEAT COUPLING POINT FRONT INFORMATION DISPLAY CONTROL HEAD FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER SEAT HEATING ELEMENT FRONT PASSENGER SEAT TEMPERATURE SENSOR FUSE 10 FUSE PANEL D (LEFT KICK PANEL) GRN WIRE HOT AT ALL TIMES LEFT FRONT SEAT TEMPERATURE SENSOR DRIVER SEAT HEATING ELEMENT LEFT SEAT HEATING BUTTON ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT SEAT HEATING BUTTON SUPPLEMENTAL RESTRAINTS SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE WHT/VIO WIRE WHT/YEL WIRE

Go to component: -> Front heated seats circuit, w/o ventilation w/ standard & comfort seats -> COUPLING STATION IN LEFT FRONT SEAT

Wiring diagram coupling station in left front seat (3 of 4)

Wiring diagram coupling station in left front seat for Audi A6 C8 (2018-2023)

Get access

BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT DRIVER BACKREST HEATING ELEMENT DRIVER SEAT BOLSTER HEATER DRIVER SEAT COUPLING POINT FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 1 FUSE 10 FUSE PANEL D (LEFT KICK PANEL) FUSE PANEL E (LEFT KICK PANEL) GRN WIRE HOT AT ALL TIMES LEFT FRONT SEAT TEMPERATURE SENSOR DRIVER SEAT HEATING ELEMENT LEFT SEAT HEATING BUTTON ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT SEAT HEATING BUTTON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE WHT WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Front heated seats circuit, w/ ventilation (1 of 2) -> COUPLING STATION IN LEFT FRONT SEAT

Wiring diagram coupling station in left front seat (4 of 4)

Wiring diagram coupling station in left front seat for Audi A6 C8 (2018-2023)

Get access

BRN WIRE BRN/YEL WIRE COUPLING POINT IN LEFT REAR SEAT COUPLING POINT IN THE LEFT REAR DOOR COUPLING STATION IN LEFT FRONT SEAT DRIVER ASSISTANCE SYSTEMS CONTROL MODULE DRIVER BACKREST HEATING ELEMENT DRIVER HEATED SEAT EXTENSION DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT BOLSTER HEATER DRIVER SEAT COUPLING POINT DRIVER SEAT CUSHION BLOWER FAN DRIVER SEAT HEATING ELEMENT DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SIDE REAR DOOR CLOSING AID MOTOR DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR DOOR LOCK UNIT DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP LEFT FOOTWELL LAMP LEFT FRONT SEAT BELT LEFT REAR BACKREST HEATING ELEMENT LEFT REAR BENCH SEAT HEATING ELEMENT LEFT REAR DOOR AMBIENT LIGHTING BULB 1 LEFT REAR DOOR CONTOUR ILLUMINATION LAMP LEFT REAR DOOR CONTOUR ILLUMINATION LAMP 2 LEFT REAR DOOR COUPLING POINT LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR LEFT REAR SEAT COUPLING STATION MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE TO DRIVER SEAT COUPLING STATION (DIAGRAM 8 OF 10) W/ AMBIENT LIGHTING W/ AUXILIARY LAMPS W/ MEMORY W/ SEAT VENTILATION W/O MEMORY WHT WIRE YEL WIRE

Go to component: -> Ground distribution circuit (7 of 10) -> COUPLING STATION IN LEFT FRONT SEAT
