Audi A6 C8 (2018-2023) coupling point in left rear door Wiring diagrams

BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COUPLING POINT IN LEFT REAR DOOR COUPLING POINT IN RIGHT REAR DOOR DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE LEFT EFFECTS SPEAKER LEFT FRONT MIDRANGE SPEAKER 2 LEFT REAR DOOR COUPLING POINT LEFT REAR MIDRANGE SPEAKER 2 LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT EFFECTS SPEAKER RIGHT FRONT MIDRANGE SPEAKER 2 RIGHT REAR DOOR COUPLING POINT RIGHT REAR MIDRANGE SPEAKER 2 RIGHT REAR TREBLE SPEAKER SOUND SYSTEMS VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE

BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COUPLING POINT IN LEFT REAR DOOR COUPLING POINT IN RIGHT REAR DOOR DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE LEFT EFFECTS SPEAKER LEFT FRONT MIDRANGE SPEAKER 2 LEFT REAR DOOR COUPLING POINT LEFT REAR MIDRANGE SPEAKER 2 LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT EFFECTS SPEAKER RIGHT FRONT MIDRANGE SPEAKER 2 RIGHT REAR DOOR COUPLING POINT RIGHT REAR MIDRANGE SPEAKER 2 RIGHT REAR TREBLE SPEAKER SOUND SYSTEMS VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE
