Audi A6 C7 (2011-2014) wastegate bypass coolant regulator recirculation valve pump Wiring diagram
This page shows the only wiring diagram for the component.wastegate bypass coolant regulator recirculation valve pump, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wastegate bypass coolant regulator recirculation valve pump (1 of 1)
A/T
BLK WIRE
BLU WIRE
BRN WIRE
CAM ADJUSTMENT ACTUATOR 1
CAM ADJUSTMENT ACTUATOR 2
CAM ADJUSTMENT ACTUATOR 4
CAM ADJUSTMENT ACTUATOR 6
CAM ADJUSTMENT ACTUATOR 7
CAM CAM ADJUSTMENT ADJUSTMENT ACTUATOR 3 ACTUATOR 5
CAMSHAFT ADJUSTMENT VALVE 1
CHAMBER E-BOX)
COOLANT FAN CONTROL MODULE
ENGINE COMPONENT POWER SUPPLY RELAY
ENGINE CONTROL MODULE
ENGINE CONTROL TRANSMISSION MODULE CONTROL MASS MODULE AIRFLOW SENSOR
EVAP CANISTER PURGE REGULATOR VALVE
FROM FUSE PANEL B (DIAGRAM 2 OF 8)
FROM POWER SUPPLY RELAY (TERMINAL 15) (DIAGRAM 1 OF 8)
FROM VOLTAGE STABILIZER (DIAGRAM 5 OF 8)
FUEL PRESSURE REGULATOR VALVE
FUSE 10
FUSE 11
FUSE 3 FUSE 12
FUSE 4
FUSE 5
FUSE 6 FUSE 2
FUSE 7 FUSE 1
FUSE 9
FUSE PANEL A (IN LEFT PLENUM FUSE 14
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR, OXYGEN SENSOR HEATER
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
LEFT ELCTRO- HYDRAULIC ENGINE MOUNT SOLENOID VALVE
MOTORONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY
NCA WIRE
OXYGEN
RED WIRE
RED/GRY WIRE
STARTER
STARTER RELAY
TO FUSE PANEL B (DIAGRAM 3 OF 8)
TRANSMISSION CONTROL MODULE
TURBO- CHARGER RECIRCULATION VALVE
VIO WIRE
W/ START/STOP SYSTEM
WASTEGATE BYPASS COOLANT REGULATOR RECIRCULATION VALVE PUMP
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (8 of 8) -> WASTEGATE BYPASS COOLANT REGULATOR RECIRCULATION VALVE PUMP
