Audi A6 C7 (2011-2014) sunroof button assembly Wiring diagram

This page shows the only wiring diagram for the component.sunroof button assembly, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram sunroof button assembly (1 of 1)

Wiring diagram sunroof button assembly for Audi A6 C7 (2011-2014)

Get access

BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 7 FUSE FUSE 11 PANEL 2 FUSE PANEL B (LEFT END OF DASH) GRN WIRE GRY/BLU WIRE HOT AT ALL TIMES NCA WIRE POWER SUNROOF CONTROL MODULE (CENTER FRONT OF ROOF) RED WIRE RED/WHT WIRE RED/YEL WIRE ROOF SHADE ROOF SHADE BUTTON 1 BUTTON 2 ROOF SHADE CONTROL MODULE SUNROOF BUTTON SUNROOF BUTTON ASSEMBLY SUNROOF MOTOR SUNROOF SHADE MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) WHT WIRE YEL WIRE

Go to component: -> Power top/sunroof circuit -> SUNROOF BUTTON ASSEMBLY
