Audi A6 C7 (2011-2014) selector lever sensor system control module (base of shift Wiring diagram
This page shows the only wiring diagram for the component.selector lever sensor system control module (base of shift, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector lever sensor system control module (base of shift (1 of 1)
A/T CVT
AUTOMATIC DIMMING INTERIOR REARVIEW MIRROR
BACKUP
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
FUSE 8
FUSE CARRIER FUSE 7
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRN/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT REAR TAILLAMP ASSEMBLY 2
LEVER ASSEMBLY)
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR TAILLAMP ASSEMBLY 2
SEDAN WAGON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (BASE OF SHIFT
TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN)
VIO WIRE
W/ LED TAIL LAMPS
W/O HIGH BEAM ASSIST
W/O LED TAIL LAMPS
WHT WIRE
YEL WIRE
Go to component: -> Backup lamps circuit -> SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (BASE OF SHIFT
