Audi A6 C7 (2011-2014) right rear heated seat temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.right rear heated seat temperature sensor, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear heated seat temperature sensor (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIAGNOSTIC INTERFACE)
FUSE
FUSE CARRIER
FUSE PANEL B
GRN WIRE
GRN/RED WIRE
GRY/BLU WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATING ELEMENT
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE PANEL F FUSE CARRIER (RIGHT REAR OF LUGGAGE COMPT)
LEFT REAR BACKREST
LEFT REAR HEATED SEAT REGULATING SWITCH
LEFT REAR HEATED SEAT TEMPERATURE SENSOR
LEFT SEAT HEATING BUTTON
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
REAR A/C DISPLAY CONTROL HEAD
RED WIRE
RED/BRN WIRE
RED/VIO WIRE
RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR BENCH SEAT HEATING ELEMENT
RIGHT REAR HEATED SEAT REGULATING SWITCH
RIGHT REAR HEATED SEAT TEMPERATURE SENSOR
RIGHT REAR SEAT HEATER (W/O ADJUSTABLE SEATS)
RIGHT SEAT HEATING BUTTON
SEAT HEATING CONTROL MODULE
VIO WIRE
YEL WIRE
Go to component -> Heated seats circuit, without ventilation (2 of 2) -> RIGHT REAR HEATED SEAT TEMPERATURE SENSOR
