Audi A6 C7 (2011-2014) right rear door control module Wiring diagrams
This page contains all the electrical diagrams for the component. right rear door control module, in which he is found in the car Audi A6 C7 (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear door control module (1 of 2)
AUTO HOLD BUTTON
BLU WIRE
BLU/BRN WIRE
BRN WIRE
CUP HOLDER W/ HEATING, COOLING ELEMENT
DISPLAY UNIT BUTTON
FUSE 5
FUSE 7
FUSE CARRIER 2
FUSE CARRIER 3
FUSE PANEL B (LEFT END OF DASH)
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
LEFT REAR ASHTRAY ILLUMINATION BULB
LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR)
LEFT REAR INTERIOR LOCKING SWITCH
LEFT REAR POWER WINDOW BUTTON
REAR A/C DISPLAY CONTROL HEAD
REAR WINDOW SHADE SWITCH ILLUMINATION
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT INSTRUMENT PANEL VENT ILLUMINATION BULB
RIGHT REAR AIR VENT ILLUMINATION BULB
RIGHT REAR ASHTRAY ILLUMINATION BULB
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR DOOR POWER WINDOW BUTTON
RIGHT SEAT HEATING BUTTON
VIO WIRE
VIO/BLU WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> RIGHT REAR DOOR CONTROL MODULE
Wiring diagram right rear door control module (2 of 2)
2.0L
3.0L
ACCESS/START AUTHORIZATION BUTTON
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CLUTCH POSITION SENSOR
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
CONTROL MODULE
DIGITAL SOUND SYSTEM CONTROL MODULE 2 (W/ BANG, OLUFSEN SOUND)
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH (W/O MEMORY)
ELECTRO- LEVEL MECHANICAL CONTROL PARKING SYSTEM BRAKE CONTROL BUTTON MODULE
FROM FUSE PANEL F (DIAGRAM 5 OF 8)
FROM MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY (DIAGRAM 7 OF 8)
FROM MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY (DIAGRAM 8 OF 8)
FROM POWER SUPPLY RELAY (TERMINAL 15) (DIAGRAM 1 OF 8)
FRONT PASSENGER MULTICONTOUR SEAT CONTROL
FUEL BRAKE LAMP PUMP SWITCH CONTROL MODULE
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2 FUSE 3
FUSE 4
FUSE 5
FUSE 5 FUSE 6
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE 9 FUSE 10
FUSE CARRIER 2
FUSE CARRIER 3 FUSE 12
FUSE PANEL
FUSE PANEL B (LEFT END OF DASH)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HORN RELAY
LEFT REAR DOOR CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RAIN/ LIGHT RECOGNITION SENSOR
REAR LID TELEPHONE CONTROL BASE PLATE MODULE
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR DOOR CONTROL MODULE (SEDAN)
VEHICLE ELECTRICAL SYSTEM
VIO WIRE
WAGON
WHT WIRE
WIPER MOTOR CONTROL MODULE
YEL WIRE
Go to component -> Power distribution circuit (3 of 8) -> RIGHT REAR DOOR CONTROL MODULE
