Audi A6 C7 (2011-2014) right front seat heater/ sensor Wiring diagram
This page shows the only wiring diagram for the component.right front seat heater/ sensor, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front seat heater/ sensor (1 of 1)
BACKREST BOLSTER HEATER
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BOLSTER HEATER
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST HEATING ELEMENT/ BOLSTER HEATER
DRIVER SEAT BACKREST BLOWER FAN
DRIVER SEAT BACKREST BLOWER FAN 2
DRIVER SEAT CUSHION BLOWER FAN
DRIVER SEAT CUSHION BLOWER FAN 2
FRONT PASSENGER SEAT BACKREST BLOWER FAN
FRONT PASSENGER SEAT BACKREST BLOWER FAN 2
FRONT PASSENGER SEAT CUSHION FAN
FRONT PASSENGER SEAT CUSHION FAN 2
FUSE CARRIER FUSE 9
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRN WIRE
HEATING ELEMENT
HEATING ELEMENT FRONT PASSENGER BACKREST HEATING ELEMENT
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE PANEL D FUSE 10 (UNDER LEFT SIDE OF DASH)
LEFT FRONT SEAT HEATER/SENSOR
LEFT FRONT SEAT VENTILATION CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT SEAT HEATER/ SENSOR
RIGHT FRONT SEAT VENTILATION CONTROL MODULE
SEAT TEMPERATURE SENSOR
SIDE BOLSTER HEATER
SIDE HEATING ELEMENT BOLSTER HEATER
TEMPERATURE SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH )
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Front heated seats circuit, with ventilation -> RIGHT FRONT SEAT HEATER/ SENSOR
