Audi A6 C7 (2011-2014) power adjustment steering column control module Wiring diagram

This page shows the only wiring diagram for the component.power adjustment steering column control module, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram power adjustment steering column control module (1 of 1)

Wiring diagram power adjustment steering column control module for Audi A6 C7 (2011-2014)

Get access

AIR BAG SPIRAL SPRING/ RETURN SPRING W/ SLIP RING (TOP OF STEERING COLUMN) BLU WIRE BLU/GRN WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM FUSE PANEL C (RIGHT END OF DASH) GRY/YEL WIRE HORN RELAY (ON RELAY & FUSE PANEL B) HORN SIGNAL ACTIVATION HOT AT ALL TIMES FUSE FUSE CARRIER HOT AT ALL TIMES FUSE FUSE PANEL B FUSE CARRIER (LEFT END OF DASH) LOW TONE HORN HIGH TONE HORN NCA WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE POWER ADJUSTMENT STEERING COLUMN CONTROL MODULE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (TOP OF STEERING COLUMN) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO/RED WIRE VIO/WHT WIRE

Go to component: -> Horn circuit -> POWER ADJUSTMENT STEERING COLUMN CONTROL MODULE
