Audi A6 C7 (2011-2014) left lower rear window antenna amplifier Wiring diagram
This page shows the only wiring diagram for the component.left lower rear window antenna amplifier, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left lower rear window antenna amplifier (1 of 1)
ANTENNA
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLUETOOTH ANTENNA
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY OPENING/ CLOSING MOTOR
DISPLAY UNIT BUTTON
FIBER OPTIC FIBER OPTIC 1 2
FUSE
FUSE 2
FUSE PANEL C (RIGHT END OF DASH) CARRIER 1 FUSE 4
GRN WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
INSTRUMENT CLUSTER CONTROL MODULE
LEFT
LEFT LOWER REAR WINDOW ANTENNA AMPLIFIER
MOST DATA BUS CIRCUIT
MULTIMEDIA SYSTEM CONTROL HEAD
NCA WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/WHT WIRE
Go to component: -> Radio circuit, with bose (4 of 4) -> LEFT LOWER REAR WINDOW ANTENNA AMPLIFIER
