Audi A6 C7 (2011-2014) left headlamp fan Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIMMER SWITCH FOG FUSE CARRIER 2 FUSE 8 FUSE PANEL C (RIGHT END OF DASH) GRN WIRE GRN/WHT WIRE GRY WIRE GRY/YEL WIRE HEADLAMP SWITCH HOT AT ALL TIMES ILLUMINATION ILLUMINATION BULB INDICATOR LAMP INDICATOR LAMP FOG LAMP INSTRUMENT PANEL, SWITCH LAMP BUTTON LAMP BUTTON REAR FOG LEFT DAYTIME RUNNING LAMP, PARKING LAMP LED MODULE LEFT FRONT SIDE MARKER LAMP BULB LEFT FRONT TURN SIGNAL BULB LEFT FRONT TURN SIGNAL BULB 2 LEFT HEADLAMP BEAM ADJUSTMENT MOTOR LEFT HEADLAMP FAN LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT HIGH LEFT LOW BEAM BEAM HEADLAMP HEADLAMP BULB BULB LEFT LED HEADLAMP ASSEMBLY LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LED HEADLAMP POWER OUTPUT MODULE 2 LEFT LED HEADLAMP POWER OUTPUT MODULE 3 LEFT LED HEADLAMP POWER OUTPUT MODULE 4 LEFT LOW BEAM HEADLAMP REFLECTOR MOTOR LEFT STATIONARY CORNERING LAMP LIGHT SWITCH ORG/BRN WIRE ORG/GRN WIRE PARKING LAMP REAR FOG LAMP INDICATOR LAMP RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE SYSTEM BUTTON NIGHT VISION VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO WIRE VIO/GRN WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
