Audi A6 C7 (2011-2014) grn/yel Wiring diagrams

3 4 DISPLAY UNIT INSTRUMENT CLUSTER CONTROL MODULE 3.0L BATTERY BATTERY INTERRUPT IGNITER BATTERY JUMP BATTERY MONITORING CONTROL MODULE (ON BATTERY) BLK WIRE BLU WIRE BRN WIRE DATA BUS ON BOARD DIAGNOSTIC INTERFACE (UNDER CENTER OF REAR SEAT) ENGINE CONTROLS SYSTEM GENERATOR, VOLTAGE REGULATOR GRN/YEL WIRE INSTRUMENT CLUSTER MAIN FUSE CARRIER (IN LUGGAGE COMPT ON BATTERY) NCA WIRE ORG/BLU WIRE ORG/BRN WIRE RED WIRE STARTER SUPPLEMENTAL RESTRAINTS SYSTEM SUPPRESSOR (IN RIGHT PLENUM CHAMBER E-BOX) TERMINAL TERMINAL 30 WIRE JUNCTON (IN CENTER PLENUM CHAMBER) VIO/BLU WIRE VIO/WHT WIRE

6 5 INTERIOR LIGHTS SYSTEM ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/YEL WIRE BLU/GRY WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CLUTCH POSITION SENSOR COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) FUSE 5 FUSE CARRIER 1 FUSE 1 FUSE CARRIER 1 FUSE 4 FUSE CARRIER 2 FUSE 5 FUSE PANEL SB FUSE PANEL SF GRN WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED LEFT PARKING BRAKE MOTOR (ON LEFT REAR CALIPER ASSEMBLY) ORG/BLK WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RIGHT PARKING BRAKE MOTOR (ON RIGHT REAR CALIPER ASSEMBLY) VIO WIRE WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DISPLAY CONTROL ASSEMBLY EXTERNAL AUDIO SOURCE CONNECTION (W/ EXTERNAL AUDIO SOURCE AUX-IN CONNECTION) FUSE 2 FUSE 4 FUSE FUSE PANEL C CARRIER 1 (RIGHT END OF DASH) GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 MULTIMEDIA SYSTEM CONTROL HEAD NCA WIRE ORG/ WIRE RED WIRE RED/BLU WIRE RED/GRY WIRE VIO WIRE W/ AUDI MUSIC INTERFACE W/ AUX-IN CONNECTION WHT WIRE WHT/GRN WIRE YEL WIRE YEL/WHT WIRE

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLUETOOTH ANTENNA BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DISPLAY OPENING/CLOSING MOTOR DISPLAY UNIT BUTTON FIBER OPTIC FIBER OPTIC 1 2 FUSE FUSE PANEL F CARRIER 3 FUSE 1 (RIGHT REAR OF LUGGAGE COMPT) GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE MOST DATA BUS CIRCUIT MULTIMEDIA SYSTEM CONTROL HEAD NCA WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/WHT WIRE

1 2 FIBER OPTIC FIBER OPTIC BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER SPEAKER CENTER SPEAKER 2 DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT) FUSE 1 FUSE 7 FUSE CARRIER FUSE FUSE 11 CARRIER GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) LEFT EFFECTS SPEAKER LEFT FRONT BASS, MIDRANGE SPEAKER LEFT REAR RIGHT REAR TREBLE TREBLE SPEAKER SPEAKER MOST DATA BUS CIRCUIT RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT EFFECTS SPEAKER RIGHT FRONT BASS, MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER, MOTOR VIO WIRE VIO/GRY WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

ANTENNA BLK WIRE BLK/WHT WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM RADIO ANTENNA ANTENNA 2 COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA DIGITAL SOUND SYSTEM CONTROL MODULE 2 FIBER OPTIC FIBER OPTIC 1 2 GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/WHT WIRE LEFT FRONT TREBLE SPEAKER, MOTOR LOWER LEFT REAR WINDOW ANTENNA AMPLIFIER MOST DATA BUS CIRCUIT NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RADIO RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE ROOF ANTENNA SATELLITE ANTENNA UPPER LEFT REAR WINDOW ANTENNA AMPLIFIER 2 VIO WIRE VIO/BLU WIRE VIO/GRY WIRE W/O TV RECEPTION WHT WIRE WHT/BRN WIRE YEL WIRE

ANTENNA ANTENNA AMPLIFIER (W/O TV RECEPTION) (LEFT SIDE OF REAR LID) ANTENNA AMPLIFIER 2 (LEFT "D" PILLAR) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTER SPEAKER CENTRAL LOCKING, ANTI-THEFT ALARM SYSTEM ANTENNA COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM FIBER OPTIC FIBER OPTIC 1 2 GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLK WIRE HOT AT ALL TIMES FUSE FUSE PANEL F CARRIER FUSE 1 (RIGHT REAR OF LUGGAGE COMPT) LEFT FRONT BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MID-BASS SPEAKER LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RADIO RADIO ANTENNA 2 RED/BLK WIRE RED/GRN WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR MID- BASS SPEAKER RIGHT REAR TREBLE SPEAKER SUBWOOFER WHT/RED WIRE

BLK WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT) FIBER OPTIC FIBER OPTIC 1 2 FUSE 1 FUSE CARRIER FUSE 7 FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MID-BASS SPEAKER LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT RED WIRE RED/BLK WIRE RED/GRN WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT LEFT EFFECTS EFFECTS SPEAKER SPEAKER RIGHT REAR MID- BASS SPEAKER RIGHT REAR TREBLE SPEAKER SUBWOOFER VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

ANTENNA BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLUETOOTH ANTENNA BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY OPENING/ CLOSING MOTOR DISPLAY UNIT BUTTON FIBER OPTIC FIBER OPTIC 1 2 FUSE FUSE 2 FUSE PANEL C (RIGHT END OF DASH) CARRIER 1 FUSE 4 GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE LEFT LEFT LOWER REAR WINDOW ANTENNA AMPLIFIER MOST DATA BUS CIRCUIT MULTIMEDIA SYSTEM CONTROL HEAD NCA WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/WHT WIRE

BLK WIRE BLK/BRN WIRE BLK/VIO WIRE BLU/BLK WIRE BLU/GRY WIRE BRAKE LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY) BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER) FUSE 12 (IN LEFT PLENUM CHAMBER E-BOX) FUSE CARRIER 3 FUSE 3 FUSE CARRIER 4 FUSE 4 FUSE PANEL A FUSE PANEL B (LEFT END OF DASH) FUSE PANEL F (RIGHT REAR OF GRN/VIO WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LUGGAGE COMPT) NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (BASE OF SHIFT LEVER ASSEMBLY) SHIFT LOCK SOLENOID (BASE OF SHIFT LEVER ASSEMBLY) TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) VIO WIRE
