Audi A6 C7 (2011-2014) front passenger nterior locking switch wiring diagram
This page shows the only wiring diagram for the component.front passenger nterior locking switch, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front passenger nterior locking switch wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER INTERIOR LOCKING SWITCH
DRIVER MEMORY SEAT CONTROL HEAD
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REARVIEW MIRROR TURN SIGNAL BULB
FRONT PASSENGER NTERIOR LOCKING SWITCH
FUSE CARRIER FUSE 4
FUSE CARRIER FUSE 6
FUSE PANEL
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
LANE CHANGE ASSISTANCE BUTTON
MIRROR ADJUSTMENT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
POWER WINDOW CONTROL HEAD
REAR LID REMOTE RELEASE BUTTON
RED/GRN WIRE
SUNROOF BUTTON
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> FRONT PASSENGER NTERIOR LOCKING SWITCH
