Audi A6 C7 (2011-2014) front interior lamp assembly Wiring diagram
This page shows the only wiring diagram for the component.front interior lamp assembly, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front interior lamp assembly (1 of 1)
AUTOMATIC DIMMING INTERIOR REARVIEW MIRROR 14 15 17 8
AUTOMATIC DIMMING INTERIOR REARVIEW MIRROR RELAY (W/ START/STOP SYSTEM)
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
BRN/VIO WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM 23 13
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
FRONT INTERIOR LAMP ASSEMBLY
FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S FRONT DOOR)
FUSE
FUSE PANEL F
HOT AT ALL TIMES FUSE CARRIER 3 FUSE 9
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
RED/GRY WIRE
RIGHT BACKUP LAMP
ROOF ELECTRONICS CONTROL MODULE (W/ HIGHLINE EQUIPMENT) (CENTER FRONT OF ROOF)
VIO WIRE
VIO/BLU WIRE
VIO/WHT WIRE
W/ HIGH BEAM ASSIST
W/O HIGH BEAM ASSIST
Go to component: -> Power mirrors circuit -> FRONT INTERIOR LAMP ASSEMBLY
