Audi A6 C7 (2011-2014) cupholder w/ heating, cooling element Wiring diagrams
This page contains all the electrical diagrams for the component. cupholder w/ heating, cooling element, in which he is found in the car Audi A6 C7 (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
cupholder w/ heating, cooling element wiring diagram (1 of 2)
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BRN WIRE
COOLING FAN CONTROL MODULE, COOLING FAN CONTROL MODULE 2
CUPHOLDER W/ HEATING, COOLING ELEMENT
DISPLAY OPENING/ CLOSING MOTOR
FRONT PASSENGER SEAT SEAT 4 PIN CONNECTOR, DRIVER SEAT 4 PIN CONNECTOR
INFORMATION ELECTRONICS CONTROL MODULE 1, MULTIMEDIA SYSTEM CONTROL HEAD
POWER STEERING CONTROL MODULE
TELEPHONE BASEPLATE
Go to component -> Ground distribution circuit (4 of 5) -> CUPHOLDER W/ HEATING, COOLING ELEMENT
cupholder w/ heating, cooling element wiring diagram (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
CUPHOLDER W/ HEATING, COOLING ELEMENT
DATA LINK CONNECTOR
DIGITAL RADIO SOUND (W/ AUDI SYSTEM SOUND CONTROL SYSTEM) MODULE
ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE
FROM FUSE PANEL F (DIAGRAM 6 OF 8)
FROM MAIN FUSE CARRIER (DIAGRAM 1 OF 8)
FRONT PASSENGER DOOR CONTROL MODULE
FUEL TANK LEAK DETECTION CONTROL MODULE
FUSE
FUSE 11 FUSE 10
FUSE 12
FUSE 2 FUSE 1 FUSE 3 FUSE 4
FUSE 2 FUSE 3 FUSE 1
FUSE 2 FUSE 5
FUSE 4 FUSE 5
FUSE 5
FUSE 6
FUSE 7 FUSE 8
FUSE 9
FUSE 9 FUSE 10 FUSE 11 FUSE 12
FUSE CARRIER 1
FUSE FUSE 4 CARRIER
FUSE FUSE 6 CARRIER
FUSE FUSE CARRIER 3 PANEL F FUSE 3 (RIGHT REAR OF LUGGAGE COMPT)
FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT)
GRN WIRE
GRY WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1 (W/ SOUND SYSTEM)
NCA WIRE
RADIO MULTIMEDIA CONTROL (W/ BOSE, HEAD 2 BANG, OLUFSEN SOUND)
REAR A/C DISPLAY CONTROL HEAD
REAR LID OPENER CONTROL MODULE
REAR LID REMOTE UNLOCKING FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
REDUCING AGENT METERING SYSTEM CONTROL MODULE
RIGHT FRONT SEAT VENTILATION CONTROL MODULE
SEAT HEATING CONTROL MODULE
SYSTEM W/ START/STOP SYSTEM
TO FUSE PANEL A (DIAGRAM 8 OF 8)
TO FUSE PANEL C (DIAGRAM 2 OF 8)
TO FUSE PANEL F (DIAGRAM 3 OF 8)
TO POWER SUPPLY RELAY 2 (TERMINAL 15) (DIAGRAM 6 OF 8)
TO SOCKETS RELAY (DIAGRAM 6 OF 8)
VIO WIRE
VIO/WHT WIRE
VOLTAGE STABILIZER (W/ START/STOP SYSTEM) (RIGHT SIDE LUGGAGE COMPT)
WAGON W/O START/STOP
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 8) -> CUPHOLDER W/ HEATING, COOLING ELEMENT
