Audi A6 C7 (2011-2014) cup holder cooling element button Wiring diagram

This page shows the only wiring diagram for the component.cup holder cooling element button, which is found in the car Audi A6 C7 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram cup holder cooling element button (1 of 1)

Wiring diagram cup holder cooling element button for Audi A6 C7 (2011-2014)

Get access

BLK WIRE BLU WIRE BRN WIRE CUP HOLDER COOLING ELEMENT BUTTON CUP HOLDER HEATING ELEMENT BUTTON CUP HOLDER W/ HEATING, COOLING ELEMENT FUSE FUSE CARRIER FUSE CARRIER FUSE FUSE PANEL F (RIGHT REAR OF LUGGAGE COMPT) GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ SOCKETS RELAY ENERGIZED RED WIRE RED/GRN WIRE RED/YEL WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT END OF DASH ) WHT WIRE YEL WIRE

Go to component: -> Heated and cooled cup holder circuit -> CUP HOLDER COOLING ELEMENT BUTTON
