4.2l, starting circuit for Audi A6 C6 facelift (2008-2011)

3.0L, 3.2L (CALA) 5.2L 4.2L 9 POSITION RELAY & FUSE PANEL (UNDER LEFT SIDE OF DASH) ACCESS/START CONTROL MODULE (BASE OF STEERING COLUMN) BATTERY BATTERY INTERRUPT IGNITER BATTERY MONITORING CONTROL MODULE BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM GENERATOR, VOLTAGE REGULATOR MAIN FUSE PANEL MAIN FUSE PANEL (E-BOX) (IN RIGHT PLENUM CHAMBER E-BOX) ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE STARTER STARTER RELAY STARTER RELAY 2 SUPPLEMENTAL RESTRAINTS SYSTEM SUPPRESSOR (IN RIGHT PLENUM CHAMBER E-BOX) WHT WIRE
