Audi A6 C6 facelift (2008-2011) passenger's side outside folding mirror Wiring diagram

This page shows the only wiring diagram for the component.passenger's side outside folding mirror, which is found in the car Audi A6 C6 facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger's side outside folding mirror (1 of 1)

Wiring diagram passenger's side outside folding mirror for Audi A6 C6 facelift (2008-2011)

Get access

AUTOMATIC DAY/NIGHT INTERIOR MIRROR BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) DAY/NIGHT DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR) DRIVER'S SIDE OUTSIDE FOLDING MIRROR FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S FRONT DOOR) FUSE 9 FUSE PANEL SB HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED PASSENGER'S SIDE OUTSIDE FOLDING MIRROR RIGHT REAR TAILLAMP CONTROL MODULE ROOF ELECTRONICS CONTROL MODULE VIO WIRE VIO/WHT WIRE WHT/YEL WIRE

Go to component: -> Automatic day/night mirror circuit -> PASSENGER'S SIDE OUTSIDE FOLDING MIRROR
