Audi A6 C6 facelift (2008-2011) left rear mid/low range speaker Wiring diagram
This page shows the only wiring diagram for the component.left rear mid/low range speaker, which is found in the car Audi A6 C6 facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear mid/low range speaker (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTER MID/HIGH RANGE
COMPUTER DATA LINES SYSTEM
DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT)
FUSE HOLDER 1 FUSE 1
FUSE PANEL SF
GRN/VIO WIRE
HOT AT ALL TIMES
LEFT FRONT BASS SPEAKER
LEFT FRONT MIDRANGE SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR MID/LOW RANGE SPEAKER
LEFT REAR TREBLE SPEAKER
LOUDSPEAKER
MOST DATA BUS CIRCUIT
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT MIDRANGE SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR RIGHT REAR TREBLE MID/LOW SPEAKER RANGE SPEAKER
SPEAKER
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Radio circuit, late production with bose (1 of 2) -> LEFT REAR MID/LOW RANGE SPEAKER
