Audi A6 C6 facelift (2008-2011) cvt except cvt w/ bose, premium radio w/ radio Wiring diagram
This page shows the only wiring diagram for the component.cvt except cvt w/ bose, premium radio w/ radio, which is found in the car Audi A6 C6 facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cvt except cvt w/ bose, premium radio w/ radio (1 of 1)
3.2L
5.2L
BLK WIRE
CLIMATRONIC CONTROL MODULE
CVT EXCEPT CVT W/ BOSE, PREMIUM RADIO W/ RADIO
DRIVER'S DOOR CONTROL MODULE (IN LEFT FRONT DOOR)
ENGINE CONTROL MODULE
FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE (ABOVE GLOVE BOX)
GRN/VIO WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/WHT WIRE
LEFT CAN-BUS DISCONNECTION PLUG
LEFT REAR DOOR CONTROL MODULE (IN LEFT REAR DOOR)
MEDIA PLAYER POSITION 1/CD CHANGER
MEDIA PLAYER POSITION 2/ CD CHANGER UNIT, MINI DISK PLAYER
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT)
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RADIO
SATELLITE RADIO
TELEPHONE TRANSCEIVER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
Go to component: -> Computer data lines circuit (1 of 3) -> CVT EXCEPT CVT W/ BOSE, PREMIUM RADIO W/ RADIO
