Audi A6 C6 facelift (2008-2011) brake pad wear ind lamp Wiring diagram
This page shows the only wiring diagram for the component.brake pad wear ind lamp, which is found in the car Audi A6 C6 facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake pad wear ind lamp (1 of 1)
ACCESS/START AUTHORIZATION BUTTON
ALL WHEEL DRIVE
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRAKE PAD WEAR IND LAMP
BRAKE SYSTEM WARNING LAMP
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL CLOCK
DIRECTIONAL STABILIZATION ASSISTANCE IND LAMP
DISPLAY UNIT
ENGINE CONTROLS SYSTEM
ENGINE COOLANT LEVEL/ TEMPERATURE (ECL/ECT) WARNING LAMP
FUEL LEVEL SENSOR, FUEL LEVEL SENSOR 2
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT AT ALL TIMES FUSE PANEL SB FUSE 15
INSTRUMENT CLUSTER CONTROL MODULE
LOW WINDSHIELD WASHER FLUID LEVEL IND LAMP
OIL PRESSURE WARNING LAMP
ORG/BLU WIRE
ORG/BRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR
OUTSIDE AIR TEMPERATURE SENSOR (BEHIND LOWER FRONT GRILLE)
PARKING BRAKE FUEL IND GAUGE LAMP
RED WIRE
RED/BLU WIRE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SHIFT INTERLOCK SYSTEM
VIO WIRE
VIO/BLK WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component: -> Instrument cluster circuit (1 of 2) -> BRAKE PAD WEAR IND LAMP
