Car Wiring Diagrams for 3.0l, cooling fan circuit for Audi A6 C5 facelift (2001-2004)

3-FOLD RELAY PANEL (LEFT REAR OF ENGINE COMPT) 8-FOLD RELAY PANEL (BEHIND LEFT SIDE OF DASH) A/C CONTROL HEAD A/C HIGH PRESSURE SENSOR AFTER- AUXILIARY ENGINE COOLANT PUMP RELAY BLK/RED WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM (LOWER LEFT "A" PILLAR) COOLANT FAN COOLANT PUMP FUSE 142 FUSE 42 FUSE PANEL (LEFT END OF DASH) FUSE 5 GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN OR START HOT W/ ECM RELAY ENERGIZED MOTRONIC ENGINE CONTROL MODULE (ECM) ORG/BLK WIRE ORG/BRN WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RUN WIRE YEL/WHT WIRE
