Audi A6 C5 facelift (2001-2004) starting system (interlock relay) Wiring diagrams
This page contains all the electrical diagrams for the component. starting system (interlock relay), in which he is found in the car Audi A6 C5 facelift (2001-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
starting system (interlock relay) wiring diagram (1 of 3)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
ENGINE CONTROL MODULE (IN ELEC BOX, LEFT SIDE OF FRESH AIR PLENUM)
EXTERIOR LIGHTS SYSTEM (BACKUP)
FUSE 31
FUSE 5
FUSE PANEL (LEFT SIDE OF DASH)
GRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
MULTIFUNCTION TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION)
OFF
ORG/BLK WIRE
ORG/BRN WIRE
PRESSURE CONTROL VALVES
RED WIRE
RUN WIRE
SOLENOID VALVES
STARTING SYSTEM (INTERLOCK RELAY)
TIPTRONIC SWITCH
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION OUTPUT SPEED SENSOR
TRANSMISSION SPEED SENSOR
VALVE BODY
VIO WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> 2.7l turbo, a/t circuit -> STARTING SYSTEM (INTERLOCK RELAY)
