Audi A6 C5 facelift (2001-2004) off head Wiring diagram
This page shows the only wiring diagram for the component.off head, which is found in the car Audi A6 C5 facelift (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off head (1 of 1)
13-FOLD RELAY PANEL (BEHIND LEFT SIDE OF DASH)
AUTO CHECK SYSTEM
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BRAKELIGHT SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
BRN WIRE
CENTRAL LOCKING CONTROL MODULE
EMERGENCY FLASHER SWITCH
FUSE
FUSE 2
FUSE PANEL (LEFT END OF DASH) FUSE
FUSE PANEL (LEFT END OF DASH) FUSE FUSE FUSE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEADLIGHTS SYSTEM
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN RUN OR START
HOT W/ LOAD REDUCTION RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER COMBINATION PROCESSOR
LAMP CONTROL MODULE
LEFT RIGHT TURN IND TURN IND
LEFT SIDE TURN SIGNAL LIGHT
LEFT TAILLAMP ASSEMBLY (WAGON) (SEDAN) 3 4
LICENSE PLATE LIGHTS
LIGHT SWITCH
OFF HEAD
OFF HEAD HEAD PARK PARK
OFF PARK
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT SIDE TURN SIGNAL LIGHT
SEDAN WAGON
STOP TAIL
SUPPLEMENTAL RESTRAINTS SYSTEM (LOWER LEFT "A" PILLAR)
TAIL
TURN PARK PARK TURN
TURN SIGNAL SWITCH
TURN TURN STOP
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component: -> Exterior lamps circuit, without drl, with driver information center -> OFF HEAD
